Media Converter 100B-TX to 100B-FX | 1300NM Wavelength | 2KM Range | SC Connector by Cabac

BRAND: CABAC
SKU: FC-110MSC
$243.90 List price: $295.20
+ −
30 Days Return Delivery Options
This media converter seamlessly connects 100B-TX to 100B-FX, operating at 1300NM with a 2KM range. Ideal for network expansion, it features an SC connector for reliable performance in various applications.

Product Name/Title: Media Converter 100B-TX to 100B-FX | 1300NM | 2KM Range | SC Connector by Matchmaster

Brand: Cabac

SKU: FC-110MSC

Alternatively Known As: Fast Ethernet Media Converter, Fibre Optic Media Converter, 100BASE-TX to 100BASE-FX Converter

Technical Specifications
  • Data Rate: 100Mbps (Fast Ethernet)
  • Wavelength: 1300nm Multimode
  • Maximum Transmission Distance: 2km
  • Connector: SC interface for fibre, RJ-45 for copper
  • Supports 10/100BaseT/TX auto-negotiating RJ-45 twisted-pair connector with Auto-MDIX
  • Built-in 10/100 switch for fibre cable connection at 100Mbps
  • Full duplex mode support on fibre connection
  • Dimensions (H x L x W): 25mm x 70mm x 100mm
  • Weight: 0.2 kg
Key Features
  • Auto-Cross over for MDI/MDIX in TP port
  • Auto-Negotiation in TP port
  • Supports link fault pass through (LFP) function
  • LED display for link/activity, full/half 10/100M
  • Converter mode with auto-change-forward (switch) function
Professional Installation Requirements
  • Installation by a qualified technician is recommended to ensure proper fibre optic and network connectivity.
Applications
  • LAN
  • FTTx
  • Telecommunication networks
Standards & Compliance
  • Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
  • Enables efficient network infrastructure reducing energy consumption by supporting auto-negotiation and link fault pass through.
Warranty Information

Standard 1 year warranty against manufacturing defects.

Available Now

The Cabac 100B-TX to 100B-FX MM 1300NM SC 2KM Media Converter is available now for immediate purchase. Ideal for LAN, FTTx, and telecommunication network applications.
