Miniature Circuit Breaker 2P 6kA | C-6A | IP20 Rated | -25°C to 70°C by Hager

BRAND: :hager
SKU: MSN206
$41.40 List price: $52.90
+
Miniature circuit breaker with 6A current and 6kA breaking capacity—ideal for residential, commercial, and light industrial applications. Built for reliable circuit protection, with a 2-pole design and wide operating temperature range.

Product Name/Title: MCB 2P 6kA C-6A 2M

Brand: Hager

SKU: MSN206

Alternatively Known As: Miniature Circuit Breaker, MCB, Circuit Protection Device

Technical Specifications
  • Rated operational voltage: 415V
  • Rated insulation voltage: 500V
  • Rated impulse withstand voltage: 4000V
  • Frequency: 50 - 60 Hz
  • Nominal tightening torque: 2.80 Nm
  • Ingress Protection (IP) class: IP20
  • Operating temperature: -25°C to 70°C
  • Dimensions (H x L x W): 83mm x 70mm x 35mm
  • Weight: 0.5 kg
Key Features
  • Rated current of 6A with a breaking capacity of 6kA.
  • 2-pole design suitable for various electrical installations.
  • Wide operating temperature range from -25°C to 70°C.
  • IP20 ingress protection for indoor use.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Residential: Homes, apartments, and small buildings
  • Commercial: Offices and retail spaces
  • Industrial: Light industrial applications requiring circuit protection
Standards & Compliance
  • Complies with AS/NZS 60898 for circuit breakers.
Environmental Benefits
  • RoHS and REACH compliant, contributing to reduced environmental impact.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The Hager MCB 2P 6kA C-6A 2M is available now for immediate purchase. Ideal for various electrical installations requiring reliable circuit protection.

MSN206 (MSN206, 150 Kb) [Download]

reach_declaration_MSN2062.pdf (reach_declaration_MSN2062.pdf, 103 Kb) [Download]

rohs_declaration_MSN2062.pdf (rohs_declaration_MSN2062.pdf, 104 Kb) [Download]

(MSN1_2_3XX_MCBS_6KA_C.pdf, 110 Kb) [Download]

(DECLARATION_24_3601_10_24.pdf, 537 Kb) [Download]

(DECLARATION_24_3593_10_24.pdf, 542 Kb) [Download]
