Moulded Case Circuit Breaker 125A 1P 25kA x160 Frame IP4X Grey Hager
Hager x160 MCCB features 125A and 25kA breaking capacity. Suited to commercial and industrial switchboards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Rated current: 125 A
- Rated ultimate short-circuit breaking capacity: 25 kA
- Rated service breaking capacity: 20 kA
- Frequency: 50 - 60 Hz
- Rated impulse withstand voltage: 8000 V
- Rated insulation voltage: 690 V
- Total power loss under IN: 11.70 W
- Electric endurance: 1000 cycles
- Mechanical operations: 4000 cycles
- Ingress Protection (IP) class: IP4X
- Nominal tightening torque: 6 - 6 Nm
- Dimensions (H x L x W): 200mm x 120mm x 100mm
- Weight: 2.5 kg
Key Features
- Rated current of 125A with a short-circuit breaking capacity of 25kA.
- Fast tripping response time of 10 ms for enhanced safety.
- IP4X ingress protection for reliable performance.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Power distribution in commercial and industrial settings
- Residential: Protection for home electrical systems
Standards & Compliance
- Complies with AS/NZS 60947-2 for safety and performance standards.
Environmental Benefits
- Designed for energy efficiency, reducing overall power loss.
Warranty Information
3 years warranty against manufacturing defects.
Available Now
The Moulded Case Circuit Breaker X160 1P 25kA 125A is available now for immediate purchase. Ideal for industrial and residential applications requiring reliable circuit protection.
