Phase Indication LED Pilot Lights 110-415V IP65 Grey Powersafe

BRAND: Powersafe
SKU: Ind-Lights
$159.50 List price: $200.50
+ −
30 Days Return Electricians Unlock Trade Access
Designed for phase indication on switchboards and distribution panels, these Powersafe LED pilot lights provide visual indication for L1, L2 and L3 phases. The unit operates at 110V - 415V AC with 22mm mounting and IP65 front protection. It uses a flame-retardant polycarbonate enclosure with screw terminal connection. See the full product details below for dimensions, temperature range and installation requirements.

Product Name/Title: Phase Indication Lights | 110V – 415V AC | IP65 Rated | LED Indicators | by Powersafe

Brand: Powersafe

SKU: Ind-Lights

Alternatively Known As: Phase Indicator Lights, Phase Presence Indicator, Three Phase Indicator, Panel Mount Phase Light, Phase Sequence Indicator

Technical Specifications
  • Voltage Range: 110V – 415V AC
  • LED Indication: Red, Yellow, Blue for L1, L2, L3 phases
  • Mounting: Panel mount, 22mm diameter
  • Enclosure: Flame-retardant polycarbonate
  • Ingress Protection: IP65 (front)
  • Operating Temperature: -20°C to +55°C
  • Connection: Screw terminals
  • Frequency: 50/60Hz
  • Dimensions (H x L x W): 30mm x 60mm x 30mm
  • Weight: 0.1 kg
Key Features
  • Provides clear visual indication of all three phases
  • Bright, long-life LED indicators for enhanced visibility
  • Robust, flame-retardant construction
  • Easy panel mounting with standard 22mm cutout
  • IP65 rated front for dust and water resistance
Professional Installation Requirements
  • Installation must be performed by a licensed electrician to ensure compliance with electrical safety standards.
Applications
  • Switchboards and distribution panels
  • Industrial control panels
  • Motor control centers
  • Commercial and industrial electrical installations
  • Generator and UPS panels
Standards & Compliance
  • Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
  • Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
  • LED technology reduces energy consumption compared to incandescent indicators
  • Long operational life minimizes replacement waste
  • RoHS compliant materials reduce hazardous substances
Warranty Information

12 months warranty against manufacturing defects.

Available Now

Powersafe Phase Indication Lights are available for immediate purchase. Ideal for electrical panels, switchboards, and industrial control systems requiring reliable phase presence indication.


FAQ

Q: What voltage range do these phase indication LED pilot lights support?
A: The voltage range is 110V - 415V AC.

Q: What protection rating does the product have?
A: The front of the product is rated IP65.


A 3-phase voltage indicator pilot light provides another option for phase status indication in electrical panels.

A 22.5mm LED pilot light is another panel-mounted option for visual status indication.

A 30mm LED pilot light can also be used for panel indication applications.

The electrical pilot light selection guide provides guidance when reviewing pilot light options for panel indication.

Available now from SCHNAP — trusted by Australian electricians and electrical contractors.
