Phased Array Digital TV Antenna | 16 Elements | Vertical/Horizontal | Balun by Matchmaster
Phased array digital TV antenna with 16 elements and vertical/horizontal polarization—ideal for homes and commercial spaces. Built for superior reception, with a balun for enhanced performance.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Phased Array Digital TV Antenna Vertical/Horizontal with Balun 16 Elements
Brand: Matchmaster
SKU: 03MM-BIGRAY
Alternatively Known As: VHF Phased Array TV Antenna, Digital TV Antenna with Balun, Long Range TV Antenna
Technical Specifications
- Elements: 16
- Band: 3
- Channels: 6-12
- Maximum Gain: 12.5dB
- Front/Back Ratio: 16dB
- Balun Type: 'F' Type
- Dimensions (H x L x W): 600mm x 150mm x 1200mm
- Weight: 2.5 kg
Key Features
- 16 element VHF phased array antenna
- Receives channels 6-12
- Snap lock element construction
- 12.7mm heavy-duty extruded elements for maximum strength and durability
- 12.5dB maximum gain
- Compact packaging for space efficiency
- Includes 'F' type balun
Professional Installation Requirements
- Professional installation by a qualified technician is recommended to ensure optimal antenna positioning and signal reception.
Applications
- Long-range and rural TV reception
- Areas with poor line of sight to broadcast stations
- Fringe reception zones requiring enhanced signal gain
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Improves signal reception reducing the need for additional electronic amplifiers, lowering energy consumption.
Warranty Information
Matchmaster Gold Lifetime Manufacturer Warranty.
Available Now
The Matchmaster Phased Array Digital TV Antenna with 16 Elements is available now for immediate purchase. Ideal for rural and fringe zone digital TV reception.
