Plaster Mount Grille 150mm | Discreet Design | Galvanised Steel | Dual Slot Option by Fantech
Plaster mount grille with a 150mm duct diameter and discreet design—ideal for residential bathrooms and ensuites. Built for efficient ventilation, featuring high-quality galvanised steel construction and options for single or dual slot airflow.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Plaster Mount Grille 150mm | Discreet Design | Galvanised Steel | Dual Slot Option by Fantech
Brand: Fantech
SKU: IDJG150
Alternatively Known As: Plaster Mount Vent Grille, Internal Ventilation Grille 150mm, Bathroom Vent Grille
Technical Specifications
- Duct Diameter: 150mm
- Oval spigot dimensions: AØ 143mm, BØ 240mm
- Hole Cutout Diameter: 210mm
- Single slot cut out size: 525 x 50mm
- Dual slot cut out size: 525 x 95mm
- High quality galvanised steel cushion head box
- Dimensions (H x L x W): 95mm x 5mm x 525mm
- Weight: 0.5 kg
Key Features
- Discreet design that blends into architecturally designed bathrooms or ensuites
- Works with duct mounted, roof mounted, or external wall mounted fans
- High quality galvanised steel cushion head box
- Oval spigot allows 150mm duct connection
- Available with single slot or dual slot for additional airflow
Professional Installation Requirements
- Professional installation by a qualified HVAC technician or licensed tradesperson is recommended to ensure proper fit and ventilation performance.
Applications
- Residential: Bathrooms, ensuites, ducted ventilation systems
- Commercial: Internal ventilation for duct mounted, roof mounted, or external wall mounted fans
Standards & Compliance
- Complies with AS/NZS 1680 – Interior Lighting and Workplace Illumination
Environmental Benefits
- Supports efficient ventilation to improve indoor air quality
- Durable galvanised steel construction reduces need for frequent replacement
Warranty Information
Standard manufacturer warranty applies. Please refer to Fantech warranty terms.
Available Now
The Fantech Plaster Mount Grille 150mm is available now for immediate purchase. Ideal for residential bathroom and ensuite ventilation applications.
