Rackmount UPS 1550VA | Lithium-Ion Battery | True Sine Wave Output | 1U Form Factor by Eaton
This 1550VA rackmount UPS features a lithium-ion battery and true sine wave output—ideal for data centers and IT infrastructure. Built for reliable power backup, it offers user-replaceable batteries and high efficiency at 97%.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Rackmount UPS 1550VA | Lithium-Ion Battery | True Sine Wave Output | 1U Form Factor by Eaton
Brand: Eaton
SKU: 9210-63045
Alternatively Known As: Eaton 5P 1550VA UPS, Eaton 5P Lithium-ion UPS, Eaton 1U Rackmount UPS, Eaton 5P 1100W UPS
Technical Specifications
- Power Capacity: 1550 VA / 1100 W
- Input Connection: 1 x C14
- Output Receptacles: 6 x C13
- Voltage: 230V nominal (adjustable 200/208/220/230/240V)
- Input Voltage Range: 160-294 V (adjustable to 150 V-294 V)
- Frequency: 50/60 Hz nominal
- Input Frequency Range: 47-70 Hz (50 Hz system), 56.5-70 Hz (60 Hz system), 40-70 Hz in low-sensitivity mode
- Topology: Line-interactive with true sine wave output
- Battery Type: Lithium-ion with integrated battery management system
- Battery Replacement: User replaceable
- Communication Ports: RS-232 (RJ45), USB (HID)
- Expansion Slot: One slot for optional Gigabit Network Card (Network-M2)
- Noise Level: <45 dB at 1 meter
- Operating Temperature: 0° to 40°C
- Relative Humidity: 0-90% non-condensing
- Form Factor: 1U Rackmount
- Efficiency at Max Load: 97%
- Auto Shutdown Function: Yes
- Phase: Single phase input and output
- Dimensions (H x L x W): 43mm x 554mm x 437mm
- Weight: 16.33 kg
Key Features
- 1550 VA / 1100 W power capacity
- Lithium-ion battery with integrated battery management system for temperature regulation and life cycle monitoring
- Line-interactive topology providing true sine wave output
- Rackmount and wallmount capable with 1U form factor
- Six C13 output receptacles and one C14 input connection
- User replaceable battery
- Optional Gigabit Network Card (Network-M2) expansion slot
- Low noise level of less than 45 dB at 1 meter
- High efficiency at maximum load (97%)
- Auto shutdown function supported
- Communication ports include RS-232 (RJ45) and USB (HID) with included cables
Professional Installation Requirements
- Professional installation by a qualified technician or electrician is recommended to ensure proper rackmount setup, electrical connections, and configuration for optimal UPS performance and safety.
Applications
- Data centers and server rooms requiring reliable power backup
- Network and telecommunications equipment protection
- Office and commercial environments needing uninterrupted power supply
- Rackmount installations in IT infrastructure
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Lithium-ion battery technology offers longer life and reduced environmental impact compared to traditional lead-acid batteries
- High efficiency reduces energy consumption and heat generation
- RoHS compliant and CE marked ensuring reduced hazardous substances
Warranty Information
Warranty details typically include coverage for manufacturing defects and battery performance; please refer to Eaton's official warranty policy for exact terms.
Available Now
The Eaton 5P Lithium Ion Model 1550VA / 1100W 1U Rackmount UPS with LCD is available now for immediate purchase. Ideal for IT infrastructure, data centers, and network equipment requiring reliable power backup.
