RCBO 1P+N 13A 10kA 10mA Sensitivity Type A C Curve 230-240V Hager

BRAND: :hager
SKU: ACA563T
$259.90 List price: $323.90
+ −
30 Days Return Electricians Unlock Trade Access
Hager 1-pole + neutral 13A RCBO features 10kA breaking capacity, 10mA Type A residual protection and C-curve tripping. Ideal for final subcircuit protection.
Technical Specifications
  • Rated short-circuit breaking capacity: 10 kA
  • Rated operational voltage: 230 - 240 V
  • Rated current: 13 A
  • Rated residual operating current: 10 mA
  • Operating temperature range: -25 to 40 °C
  • Endurance: 2000 mechanical operations
  • Dimensions (H x L x W): 83mm x 68mm x 35mm
  • Weight: 0.5 kg
Key Features
  • 1P+N configuration for single-phase circuits.
  • 10kA short-circuit breaking capacity.
  • Type A residual current protection.
  • IP20 ingress protection rating.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Residential: Homes, apartments, and small buildings
  • Commercial: Offices and retail spaces
  • Industrial: Light industrial applications requiring circuit protection
Standards & Compliance
  • Complies with AS/NZS 3000 for electrical installations.
Environmental Benefits
  • Designed to improve electrical safety and reduce the risk of electrical fires.
Warranty Information

2 years warranty against manufacturing defects.

Available Now

The Hager RCBO 1P+N 10kA C-13A 10mA A Class is available now for immediate purchase. Ideal for residential and commercial electrical safety applications.

Data Sheet (ACA563T, 151 Kb) [Download]

Certificate (PEP_ADA513D_HAGER_HAGE-00645-V01.03-EN_08092022.pdf, 357 Kb) [Download]

Certificate (reach_declaration_ACA563T.pdf, 103 Kb) [Download]

Certificate (RoHS-declaration-ACA563T.pdf, 33 Kb) [Download]

Data Sheet (ACA566T.webp, 290 Kb) [Download]

Certificate (ID1_DD_RCBO_6A5013E.pdf, 320 Kb) [Download]
