RCCB 4P 63A 30mA | A Class | IP20 Protection | DIN Rail by Hager
RCCB with 4-pole design and 63A, 30mA rating—ideal for residential and commercial safety. Built for comprehensive protection, with IP20 ingress protection and DIN rail mounting.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: RCCB 4P 63A 30mA A Class
Brand: Hager
SKU: CDA463T
Alternatively Known As: Residual Current Circuit Breaker, Safety Switch, RCD, RCCB
Technical Specifications
- Type of pole: 3P+N
- Rated operational voltage: 230 - 400 V
- Rated insulation voltage: 500 V
- Rated impulse withstand voltage: 4000 V
- Frequency: 50 Hz
- Nominal tightening torque: 2.80 Nm
- Total power loss under IN: 19.7 W
- Electric endurance: 2000 cycles
- Mechanical operations: 4000
- Dimensions (H x L x W): 83mm x 70mm x 70mm
- Weight: 0.5 kg
Key Features
- 4-pole design for comprehensive protection
- Rated current of 63A and residual current of 30mA
- IP20 ingress protection for indoor use
- Suitable for DIN rail mounting
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, and small buildings
- Commercial: Offices, retail spaces, and industrial applications
Standards & Compliance
- Complies with AS/NZS 3000 for electrical installations.
Environmental Benefits
- RoHS compliant, contributing to reduced environmental impact.
- Commitment to improving environmental performance and reducing carbon footprint.
Warranty Information
2 years warranty against manufacturing defects.
Available Now
The Hager RCCB 4P 63A 30mA A Class is available now for immediate purchase. Ideal for residential and commercial electrical safety applications.
