RCD Safety Switch 2P 25A 30mA IP20 230V DIN Rail Hager
Hager RCD Safety Switch 2P 25A features IP20 protection, 230V rated. Suited to switchboard safety switch upgrades.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Type of pole: 1P+N
- Rated operational voltage: 230V
- Rated insulation voltage: 500V
- Rated impulse withstand voltage: 4000V
- Nominal tightening torque: 2.80 Nm
- Electric endurance: 2000 cycles
- Mechanical operations: 4000 cycles
- Max operating voltage: 253V
- Frequency: 50Hz
- Total power loss under IN: 2.32W
- Dimensions (H x L x W): 83mm x 70mm x 35mm
- Weight: 0.5 kg
Key Features
- Rated current of 25A and residual operating current of 30mA.
- Suitable for DIN rail mounting.
- IP20 ingress protection rating.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, and small buildings
- Commercial: Offices and retail spaces
- General: Any electrical installation requiring residual current protection
Standards & Compliance
- Complies with AS/NZS 3000 for electrical installations.
Environmental Benefits
- RoHS compliant, contributing to reduced environmental impact.
- Commitment to improving environmental performance by reducing carbon footprint.
Warranty Information
2 years warranty against manufacturing defects.
Available Now
The Hager RCCB 2P 25A 30mA A Class is available now for immediate purchase. Ideal for residential and commercial electrical safety applications.
