Straight Quick Connector 25mm M25 IP66 Rated Grey Cabac
Designed for 25mm conduit, this straight quick connector features an M25 x 1.5 thread with self-locking push-fit installation that requires no tools. Manufactured from Polyamide nylon (PA6), it provides IP66 ingress protection, UL94 V-0 flame retardancy, UV resistance, and anti-static performance for demanding installations. Complies with AS/NZS 3000 Wiring Rules for electrical installations. Continue below to review the complete specifications, installation requirements, and application details.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Conduit Size: 25mm
- Thread Size: M25 x 1.5
- Material: Polyamide nylon (PA6)
- Temperature Rating: -40 to +115°C (intermittent up to +150°C)
- Ingress Protection: IP66
- Flame Retardant: UL94 V-0
- Installation: Self-locking push-fit, no tools required
- Dimensions (H x L x W): 30mm x 60mm x 30mm
- Weight: 0.1 kg
Key Features
- Made from high quality polyamide nylon, halogen, phosphor, and cadmium free
- Self-locking push-fit installation onto conduit with no tools required
- IP66 rated ingress protection
- UV resistant and flame retardant with UL94 V-0 rating
- Temperature rating from -40 to +115 degrees Celsius, intermittent up to +150 degrees Celsius
- Supplied complete with locknut
- Anti-static and RoHS compliant
Professional Installation Requirements
- Installation by a qualified electrician is recommended to ensure compliance with electrical standards and secure fitting.
Applications
- Cable management in residential, commercial, and industrial electrical installations
- Use with low fire hazard conduits for safe wiring protection
- Suitable for environments requiring IP66 ingress protection
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Halogen, phosphor, and cadmium free materials reduce environmental toxicity
- RoHS compliant ensuring reduced hazardous substances
- Flame retardant and self-extinguishing properties enhance safety and reduce fire risk
Warranty Information
Standard manufacturer warranty against defects applies.
Available Now
The Cabac Straight Quick Connector 25MM M25 is available for immediate purchase, ideal for electrical conduit installations requiring low fire hazard and high ingress protection.
FAQ
Q: What conduit size and thread does this connector support?
A: It is designed for 25mm conduit and features an M25 x 1.5 thread.
Q: What features help this connector perform in demanding environments?
A: It offers IP66 ingress protection, self-locking tool-free installation, UL94 V-0 flame retardancy, UV resistance, anti-static properties, and durable Polyamide nylon (PA6) construction.
Pair this straight quick connector with a straight gland fitting for secure corrugated conduit terminations.
A straight gland provides a compatible conduit entry solution for matching installation requirements.
Install a sweep bend to create smooth conduit direction changes while maintaining protected cable routing.
