Straight Quick Connector 32mm M32 IP66 Rated Grey Cabac
Designed for 32mm conduit, this straight quick connector features an M32 x 1.5 thread with self-locking push-fit installation that requires no tools. Manufactured from halogen-free Polyamide nylon (PA6), it delivers IP66 ingress protection, UL94 V-0 flame retardancy, UV resistance, and anti-static performance. Complies with AS/NZS 3000 Wiring Rules for electrical installations. Review the complete specifications, installation requirements, and application details below.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Conduit Size: 32mm
- Thread Size: M32 x 1.5
- Material: Polyamide nylon (PA6)
- Temperature Rating: -40 to +115°C (intermittent to +150°C)
- Ingress Protection: IP66
- Flame Retardant: UL94 V-0
- Installation: Self-locking push-fit, no tools required
- Dimensions (H x L x W): 32mm x 50mm x 32mm
- Weight: 0.1 kg
Key Features
- Made from high quality polyamide nylon, halogen, phosphor and cadmium free
- Self-locking push-fit installation onto conduit with no tools required
- IP66 rated ingress protection
- UV resistant and flame retardant with UL94 V-0 rating
- Temperature rating from -40 to +115 degrees Celsius (intermittent to +150 degrees Celsius)
- Anti-static and RoHS compliant
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with electrical safety standards and proper conduit fitting.
Applications
- Electrical conduit installations requiring secure, liquid-tight connections
- Industrial and commercial wiring systems
- Low fire hazard conduit systems
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Halogen, phosphor and cadmium free materials reduce environmental toxicity
- RoHS compliant ensuring restriction of hazardous substances
- Durable and UV resistant for long service life reducing replacement waste
Warranty Information
Standard manufacturer warranty applies. Please refer to Cabac warranty terms for details.
Available Now
The Cabac Straight Quick Connector 32MM M32 is available now for immediate purchase. Ideal for electrical conduit installations requiring secure, liquid-tight connections with low fire hazard properties.
FAQ
Q: What conduit size and thread does this connector support?
A: It is designed for 32mm conduit and features an M32 x 1.5 thread.
Q: What features make this connector suitable for industrial conduit installations?
A: It provides IP66 ingress protection, tool-free self-locking installation, UL94 V-0 flame retardancy, UV resistance, anti-static performance, and durable halogen-free Polyamide nylon (PA6) construction.
Pair this straight quick connector with a straight gland fitting for secure corrugated conduit terminations.
A straight gland provides a compatible conduit entry solution for matching conduit installations.
Install a sweep bend to create smooth conduit direction changes while maintaining protected cable routing.
The conduit fittings Australia guide explains how conduit connection components are selected for electrical installations.
