Straight Quick Connector 40mm M40 IP66 Rated Grey Cabac
Designed for 40mm conduit, this straight quick connector features an M40 x 1.5 thread with self-locking push-fit installation that requires no tools. Manufactured from Polyamide nylon (PA6), it delivers IP66 ingress protection, UL94 V-0 flame retardancy, UV resistance, and anti-static performance for demanding conduit installations. Complies with AS/NZS 3000 Wiring Rules for electrical installations. See the detailed specifications below for installation requirements, dimensions, and application guidance.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Conduit Size: 40mm
- Thread Size: M40 x 1.5
- Material: Polyamide nylon (PA6)
- Temperature Rating: -40 to +115°C (intermittent up to +150°C)
- Ingress Protection: IP66
- Flame Retardant: UL94 V-0
- Installation: Self-locking push-fit, no tools required
- Dimensions (H x L x W): 40mm x 60mm x 40mm
- Weight: 0.1 kg
Key Features
- Made from high quality polyamide nylon, free from halogen, phosphor, and cadmium
- Self-locking push-fit installation onto conduit with no tools required
- IP66 rated ingress protection
- UV resistant and flame retardant with UL94 V-0 rating
- Temperature rating from -40 to +115 degrees Celsius (intermittent up to +150 degrees Celsius)
- Supplied complete with locknut
- Anti-static and RoHS compliant
Professional Installation Requirements
- Installation by a qualified electrician or trained professional is recommended to ensure compliance with electrical standards and secure fitting.
Applications
- Cable management in industrial and commercial electrical installations
- Use with low fire hazard conduits in residential and commercial buildings
- Suitable for environments requiring flame retardant and halogen-free fittings
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Halogen, phosphor, and cadmium free materials reduce environmental toxicity
- Flame retardant and self-extinguishing properties enhance safety and reduce fire risk
- RoHS compliant ensuring reduced hazardous substances
Warranty Information
Standard manufacturer warranty against defects applies.
Available Now
The Cabac Straight Quick Connector 40MM M40 is available now for immediate purchase. Ideal for use with low fire hazard conduits in electrical cable management systems.
FAQ
Q: What conduit size and thread does this connector support?
A: It is designed for 40mm conduit and features an M40 x 1.5 thread.
Q: What features make this connector suitable for professional electrical installations?
A: It provides IP66 ingress protection, self-locking tool-free installation, UL94 V-0 flame retardancy, UV resistance, anti-static properties, and durable Polyamide nylon (PA6) construction.
Pair this straight quick connector with a straight gland fitting for secure corrugated conduit terminations.
A straight gland provides a compatible conduit entry solution for matching conduit installations.
Install a sweep bend to create smooth conduit direction changes while maintaining protected cable routing.
