Straight Quick Connector 50mm M50 IP66 Rated Grey Cabac
Designed for 50mm conduit, this straight quick connector features an M50 x 1.5 thread with self-locking push-fit installation that requires no tools. Manufactured from Polyamide nylon (PA6), it delivers IP66 ingress protection, UV resistance, anti-static performance, and UL94 V-0 flame retardancy for demanding conduit installations. Complies with AS/NZS 3000 Wiring Rules and is suited for AS/NZS 2053 conduit installations. Review the complete specifications below for installation guidance, dimensions, and application details.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Conduit Size: 50mm
- Thread Size: M50 x 1.5
- Material: Polyamide nylon (PA6)
- Temperature Rating: -40 to +115°C (intermittent up to +150°C)
- Ingress Protection: IP66
- Flame Retardant: UL94 V-0
- Installation: Self-locking push-fit, no tools required
- UV Resistant
- Anti-static and RoHS compliant
- Dimensions (H x L x W): 50mm x 50mm x 50mm
- Weight: 0.1 kg
Key Features
- Made from high quality polyamide nylon, free from halogen, phosphor, and cadmium
- Self-locking push-fit installation onto conduit with no tools required
- IP66 rated ingress protection
- UV resistant and flame retardant with UL94 V-0 rating
- Temperature rating from -40 to +115 degrees Celsius, intermittent up to +150 degrees Celsius
- Supplied complete with locknut
- Anti-static and RoHS compliant
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with electrical standards and secure fitting.
Applications
- Cable management in industrial and commercial electrical installations
- Use with CABFLX low fire hazard conduits
- Suitable for environments requiring flame retardant and halogen-free fittings
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Halogen, phosphor, and cadmium free materials reduce environmental toxicity
- Flame retardant and self-extinguishing properties enhance safety and reduce fire risk
- RoHS compliant ensuring reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies. Please refer to Cabac warranty terms for details.
Available Now
The Cabac Straight Quick Connector 50MM M50 is available now for immediate purchase. Ideal for electrical conduit installations requiring low fire hazard and high ingress protection.
FAQ
Q: What conduit size and thread does this connector support?
A: It is designed for 50mm conduit and features an M50 x 1.5 thread.
Q: What features make this connector suitable for electrical conduit installations?
A: It provides IP66 ingress protection, self-locking tool-free installation, UV resistance, anti-static performance, UL94 V-0 flame retardancy, and durable Polyamide nylon (PA6) construction.
