Terminal Block Inline 2 Pole Pack of 30 MajorTech
MajorTech terminal block features an inline 2 pole design supplied in a pack of 30. Ideal for joining and terminating electrical cable.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: 2-Pole Splitter Connector Block, Inline Terminal Block, Electrical Cable Joining Block, LT-422B
Technical Specifications
- Product Type: 2-pole splitter connector block
- Pack Quantity: 30 pieces
- Rated Voltage: 450 V
- Rated Current: 32 A
- Voltage Resistance: 4 kV
- Connection Type: Screwless
- Conductor Configuration: Four conductors connected in parallel
- Compatible Conductor Size: Stranded 0.4–2.5 mm²; solid core 0.5–4 mm²
- Strip Length: 11–12 mm
- Operating Temperature: -40°C to +105°C
- Manufacturer Standard Reference: IEC terminal-block standard
- Manufacturer Product Reference: LT-422 / LT-422B range
- Dimensions (H x L x W): 14.3mm x 39.3mm x 23.3mm
- Weight: 0.18 kg
Key Features
- Inline 2-pole design for joining and branching electrical cables
- Allows four conductors to be connected in parallel
- Screwless connection for fast installation
- Suitable for modular switch and socket wiring applications
- High dielectric resistance rated at 4 kV
- Supplied as a 30-piece pack
Professional Installation Requirements
- Connection to fixed wiring or mains-voltage circuits should be performed by a licensed electrician in accordance with AS/NZS 3000 and applicable local electrical regulations. Follow the manufacturer's strip-length, conductor-size and voltage/current ratings.
Applications
- Joining electrical cables
- Branching or splitting power to multiple points
- Internal wiring of modular switches and sockets
- Electrical distribution and cable termination
- Low-voltage control and general wiring applications within the rated limits
Standards & Compliance
- AS/NZS IEC 60947.7.1:2015 is the applicable Australian/New Zealand terminal-block standard for screwless clamping units; the manufacturer states IEC standard approval, but Australian conformity for this specific pack is not independently confirmed.
- Installation applications should comply with AS/NZS 3000:2018 Wiring Rules.
Environmental Benefits
- Reusable terminal-block construction supports repairable and maintainable wiring rather than permanent cable joins.
- Durable electrical components can reduce replacement frequency and associated installation waste.
- Plastic and metal components may be separable for appropriate end-of-life recycling subject to local recycling facilities.
Warranty Information
Covered by Major Tech's standard product warranty from the date of purchase or delivery, whichever is later, subject to proof of purchase and exclusions for incorrect use, abuse, normal wear, electrical surges, unauthorised alterations and inadequate maintenance. Major Tech also lists an extended warranty for VETi 3 products; confirm the applicable Australian warranty terms with the distributor.
Available Now
Available through MajorTech and authorised Australian electrical distributors, subject to distributor stock.
