Terminal Block Inline 3 Pole 10 Pack MajorTech
MajorTech terminal block features an inline 3 pole design and 10 pack. Ideal for cable joining and termination in general wiring.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: VETi 3 LT-933B, 3-Pole Splitter Connector, Inline Cable Connector Block, Quick Wire Connector
Technical Specifications
- Product Type: Splitter connector block
- Pole Configuration: 3 pole
- Pack Quantity: 10 pieces
- Rated Voltage: 450 V
- Rated Current: 32 A
- Voltage Resistance: 4 kV
- Compatible Conductor Size: 0.4–2.5 mm² stranded; 0.5–4 mm² solid core
- Strip Length: 11–12 mm
- Operating Temperature: -40°C to +105°C
- Connection Type: Screwless push-in connection
- Reference Standard: IEC standard
- Dimensions (H x L x W): 14.3mm x 48.3mm x 39.3mm
- Weight: 0.18 kg
Key Features
- Three-pole parallel splitter configuration
- Designed for multi-wire distribution, branching and cable termination
- Screwless connection design for quick installation
- Supports conductors up to 4 mm² solid core
- High 450 V voltage rating and 32 A current rating
- Supplied as a 10-piece pack
Professional Installation Requirements
- Mains electrical installation should be carried out by a licensed electrician in accordance with the applicable state or territory requirements and AS/NZS 3000. Confirm that the conductor size, circuit protection and installation method are suitable for the connector rating.
Applications
- General wiring and cable joining
- Parallel cable distribution and branching
- Lighting and power circuit termination
- Residential, commercial and industrial wiring work
- Electrical enclosure and switchboard wiring where suitable
Standards & Compliance
- AS/NZS 3000:2018 Wiring Rules apply to the selection, installation and use of cable connection devices in Australian electrical installations; product-specific AS/NZS certification was not verified.
Environmental Benefits
- Durable connector construction can reduce replacement frequency and associated wiring waste
- Copper conductor components can be recovered through appropriate metal recycling streams at end of service life
Warranty Information
Major Tech’s Australian warranty policy lists VETi 3 products with a 15-year extended warranty, subject to product registration, proof of purchase and the manufacturer’s warranty conditions.
Available Now
Available through MajorTech and authorised Australian electrical distributors, subject to distributor stock levels.
