Trade Discount 25%
WiFi 6 Access Point Dual-Band 1.5Gbps Ceiling/Wall Mount Ness
Ness WiFi 6 access point features dual-band operation, 1.5Gbps speed and ceiling or wall mounting. Ideal for wireless network installs.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: TP-Link EAP653, AX3000 Ceiling-Mount Wi-Fi 6 Access Point, Omada Wi-Fi 6 Access Point, PoE Wireless Access Point
Technical Specifications
- Model: EAP653 V1
- Wireless Standard: IEEE 802.11ax/ac/n/g/b/a
- Wireless Bands: Dual-band 2.4 GHz and 5 GHz
- Maximum Wireless Speed: 2,976 Mbps aggregate; 574 Mbps at 2.4 GHz and 2,402 Mbps at 5 GHz
- Network Interface: 1 × Gigabit Ethernet RJ-45 port
- Power Input: IEEE 802.3at PoE+ or 12 V DC; power adapter not included
- Power Consumption: Up to 13.98 W
- Antenna: Internal omnidirectional; 2 × 4 dBi at 2.4 GHz and 2 × 5 dBi at 5 GHz
- Wireless Capacity: Up to 16 SSIDs; 8 per band
- Management: Omada SDN, web interface and Omada app support
- Security: WPA3, guest network, captive portal and 802.1X authentication
- Operating Temperature: 0°C to 40°C
- Operating Humidity: 10% to 90% relative humidity, non-condensing
- Mounting: Ceiling, wall, junction box or T-bar with mounting kits included
- Dimensions (H x L x W): 33.6mm x 160mm x 160mm
- Weight: 0.38 kg
Key Features
- Wi-Fi 6 dual-band operation for business and residential network installations
- AX3000 wireless performance with up to 2,976 Mbps combined data rate
- Powered through a single Ethernet cable using 802.3at PoE+
- Supports centralised Omada SDN cloud and local network management
- MU-MIMO, OFDMA, 1024-QAM and 160 MHz channel support
- Seamless roaming, mesh networking, band steering and load balancing
- Internal omnidirectional antennas for discreet ceiling or wall installation
- Supports up to 250 concurrent clients according to the manufacturer
Professional Installation Requirements
- Installation should be completed by a competent network installer, with the mounting surface, Ethernet cabling and PoE equipment selected for the installation environment. Any associated mains-powered PoE switch or injector must be installed in accordance with applicable Australian electrical requirements.
Applications
- Business Wi-Fi networks
- Residential wireless network installations
- Offices, classrooms, hotels and cafés
- CCTV and security network infrastructure
- Managed guest Wi-Fi systems
- High-density wireless coverage using multiple access points
Standards & Compliance
- AS/NZS 62368.1:2022 or applicable current edition for audio, video, information and communication technology equipment safety
- AS/NZS 4268 for radio equipment and systems operating in the 2.4 GHz and 5 GHz bands
- AS/NZS CISPR 32 for electromagnetic emissions from multimedia equipment
- Australian ACMA and RCM requirements apply to wireless and electrical equipment supplied in Australia
Environmental Benefits
- PoE operation allows power and data to be delivered over one Ethernet cable, reducing separate cabling at the access-point location
- Low-power operation of approximately 13.98 W helps limit energy consumption during continuous network use
- Centralised management and firmware support can extend service life and reduce premature hardware replacement
- Compact enclosure and mounting hardware minimise installation material requirements
Warranty Information
Ness Corporation warranty: 3 years from the date of purchase for Ness manufactured or supplied products, subject to the published warranty terms and Australian Consumer Law.
Available Now
Available through Ness Corporation and authorised Australian distributors, subject to current stock availability.
