20 Pin Relay Module 24V DC 8 Electromechanical Relays Compact Design by Allen-Bradley
The 20 Pin Relay Module operates at 24V DC and features 8 electromechanical relays, making it ideal for industrial automation control systems. With a compact design and versatile switching capabilities, this relay board is perfect for manufacturing process control and machine control panels, ensuring reliable performance in demanding environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: 20 Pin Relay Module, 24V DC Relay Board, Industrial Control Relay, Allen-Bradley Relay Module
Technical Specifications
- Relay Type: Electromechanical
- Number of Relays: 8
- Pin Configuration: 20-pin
- Operating Voltage: 24V DC
- Contact Rating: Standard industrial relay ratings
- Mounting: Panel or socket mount compatible
- Dimensions (H x L x W): 50mm x 120mm x 100mm
- Weight: 0.3 kg
Key Features
- 20-pin configuration for multiple relay control
- Operates at 24V DC
- Contains 8 relays for versatile switching
- Compact and reliable design suitable for industrial environments
Professional Installation Requirements
- Installation by a qualified electrician or automation technician is recommended to ensure proper wiring and safety compliance.
Applications
- Industrial automation control systems
- Manufacturing process control
- Electrical relay switching applications
- Machine control panels
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption reduces energy usage in control systems
- Durable design minimizes waste and replacement frequency
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Allen-Bradley AB IFM Relay 20PIN Master 24V DC 8 Relay is available now for immediate purchase. Ideal for industrial automation and control system applications.
