24VDC Contactor 2NC 12A AC3 | Compact TeSys K Design | High Electrical Durability | @Pack of 1 | by Clipsal
The 24VDC Contactor is designed for reliable motor control with 2 normally closed contacts and a 12A AC-3 rated current. Ideal for industrial automation panels and HVAC systems, this compact TeSys K design ensures high electrical durability and energy efficiency, making it perfect for various applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 24VDC Contactor 2NC 12A AC3 | Compact TeSys K Design | High Electrical Durability | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHLP2K1201BD
Alternatively Known As: 24VDC Contactor, TeSys K Contactor, 2NC 12A Contactor, SCHLP2K1201BD, Clipsal Motor Contactor
Technical Specifications
- Control Voltage: 24V DC
- Contact Configuration: 2 Normally Closed (NC)
- Rated Operational Current: 12A (AC-3, 440V)
- Utilization Category: AC-3
- Number of Poles: 3P
- Coil Consumption: 2.4W (holding)
- Electrical Durability: 1 million cycles
- Mechanical Durability: 30 million cycles
- Mounting: DIN rail or screw
- Standards: IEC 60947-4-1, EN 60947-4-1
- Dimensions (H x L x W): 58mm x 60mm x 45mm
- Weight: 0.25 kg
Key Features
- 24V DC control voltage
- 2 Normally Closed (NC) contacts
- 12A AC-3 rated current
- Compact TeSys K design
- High electrical durability
- Suitable for reversing applications
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with local electrical regulations and standards.
Applications
- Motor control circuits
- Industrial automation panels
- HVAC systems
- Lighting control
- Pumping stations
Standards & Compliance
- Complies with AS/NZS 60947 for low-voltage switchgear and controlgear.
Environmental Benefits
- Energy-efficient coil reduces power consumption.
- Long operational life minimizes replacement waste.
- RoHS compliant materials for reduced environmental impact.
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
Available for immediate purchase. Ideal for industrial motor control, automation panels, and HVAC systems.
