3 Pole Contactor 250kW 250-500VAC VDC 1NO 1NC Auxiliary NHP
3 pole contactor with 250-500VAC VDC range and 1NO 1NC auxiliary—ideal for industrial motor control and commercial HVAC systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Rated operation current at AC 3, 400 V: 460 A
- Rated operation power at AC 3, 400 V: 250 kW
- Rated control supply voltage at AC 50 Hz: 250-500 V
- Rated control supply voltage at DC: 250-500 V
- Power consumption AC coil pickup: 950 VA
- Power consumption DC coil pickup: 885 W
- Degree of protection: IP00
- Mounting method: Screw mounting
- Dimensions (H x L x W): 268mm x 216mm x 186mm
- Weight: 12 kg
Key Features
- 3 Pole contactor with 1 Normally Open and 1 Normally Closed auxiliary contact.
- Rated for operation at 250 kW with a voltage range of 250 to 500 VAC and VDC.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Motor control and automation systems
- Commercial: HVAC systems and large electrical installations
Standards & Compliance
- Complies with AS/NZS 3000 for electrical installations.
Environmental Benefits
- Efficient power management reduces energy consumption and operational costs.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The S+S CA9 Contactor 250kW is available now for immediate purchase, ideal for industrial and commercial applications.
