33kV High Voltage Phasing Stick | 36kV Full Scale | Neon Indicator & Phase Comparator | Lightweight by Majortech
The 33kV High Voltage Phasing Stick features a 36kV full scale voltage range and neon indicator—ideal for testing grounded or ungrounded electrical systems. Built for trained electrical professionals, it ensures accurate voltage detection and safety with its lightweight, durable design.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 33kV High Voltage Phasing Stick | 36kV Full Scale | Neon Indicator & Phase Comparator | Lightweight by Majortech
Brand: Majortech
SKU: MT33KV
Alternatively Known As: High Voltage Phasing Stick, 33kV Voltage Detector, High Voltage Phase Comparator, Electrical Phasing Stick
Technical Specifications
- Full scale voltage range: 36kV
- Maximum voltage range: 40kV
- Frequency range: 50 or 60Hz
- Total resistance: 19.68MΩ
- Response time: less than 1 second
- Neon threshold voltage: 1.2kV
- Neon fully lit at: 1.5kV
- Display type: Neon & panel meter
- Handle material: Composite with polyurethane
- Front end material: Fibreglass wound tubing
- Operating temperature range: -25°C to 55°C
- Operating humidity range: 20 to 96% RH
- Safety standard: IEC61481
- Dimensions (H x L x W): n/a mm x 1440mm x n/a mm
- Weight: 2.4 kg
Key Features
- All-in-one meter including Phase Comparator with colour coded scale indication
- Voltage Detector with Neon Indication
- Scaled Voltmeter for accurate voltage measurement
- Dual pole instrument with high quality glass fibre front ends
- Composite polyurethane main body moulding for tough and lightweight construction
- Analogue colour coded dual scales (Green = in phase, Red = out of phase)
- Bright neon indicator for easy visibility and voltage detection above 1200VAC
- Housed in a high quality plastic case with shock absorbing foam
- Suitable for indoor and outdoor use
Professional Installation Requirements
- Should be used by trained electrical professionals familiar with high voltage safety procedures to ensure accurate testing and personal safety.
Applications
- Testing of grounded or ungrounded electrical systems
- Checking voltage fuses
- Testing for correct phase connections
- Verifying absence of high voltage on de-energized lines or apparatus
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable construction reduces need for frequent replacements
- Lightweight design reduces material usage and transportation emissions
Warranty Information
Warranty details available upon request from Majortech; typically includes coverage against manufacturing defects.
Available Now
The Majortech 33kV High Voltage Phasing Stick is available now for immediate purchase. Ideal for electrical testing and maintenance in industrial and utility applications.
