3P NSX160H Molded Case Circuit Breaker Frame | 160A Rated Current | 36kA Breaking Capacity | by Clipsal
The 3P NSX160H Molded Case Circuit Breaker Frame is designed for robust electrical distribution, featuring a rated current of 160A and a high breaking capacity of 36kA at 415V AC. Ideal for commercial and industrial applications, this frame ensures reliable circuit protection and easy integration into Schneider Electric/Clipsal panel systems, making it perfect for demanding environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 3P NSX160H Molded Case Circuit Breaker Frame | 160A Rated Current | 36kA Breaking Capacity | by Clipsal
Brand: Clipsal
SKU: SCHLV430404
Alternatively Known As: NSX160H MCCB Frame, 3 Pole NSX160H, Schneider NSX160H Without Trip Unit, LV430404, MCCB Shell Only
Technical Specifications
- Type: Molded Case Circuit Breaker Frame (without trip unit)
- Poles: 3
- Rated Current Frame: 160A
- Breaking Capacity: 36kA at 415V AC
- Mounting: Fixed
- Standards: IEC 60947-2 compliant
- Compatible Trip Units: NSX160 series (not included)
- Terminal Type: Front connection
- Dimensions (H x L x W): 161mm x 86mm x 105mm
- Weight: 3.5 kg
Key Features
- 3-pole molded case circuit breaker frame
- High breaking capacity (H) up to 36kA at 415V AC
- Compatible with NSX160 trip units (not included)
- Robust and reliable design for demanding environments
- Easy integration into Schneider Electric/Clipsal panel systems
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 and local regulations.
Applications
- Commercial and industrial electrical distribution panels
- Main and sub-main switchboards
- Motor control centers
- Protection of electrical circuits in buildings and infrastructure
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 60947.2 – Low-voltage switchgear and controlgear
Environmental Benefits
- Supports efficient electrical distribution, reducing energy losses
- Long service life minimizes replacement waste
- Recyclable materials used in construction
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
Available for immediate purchase. Ideal for commercial and industrial switchboards requiring reliable circuit protection and modularity.
