3P OLD Contactor 22kW | 1NO & 1NC Auxiliary Contacts | 220V AC Coil | by Clipsal
The 3P OLD Contactor 22kW is designed for reliable industrial motor control, featuring a robust 22kW rated operational power at 400V AC-3 and 1 Normally Open (NO) and 1 Normally Closed (NC) auxiliary contact. With a coil voltage of 220V AC and high electrical endurance, it's perfect for automation panels, HVAC systems, and lighting control circuits, ensuring efficient energy management in industrial applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 3P OLD Contactor 22kW | 1NO & 1NC Auxiliary Contacts | 220V AC Coil | by Clipsal
Brand: Clipsal
SKU: SCHLC1D40M7
Alternatively Known As: Clipsal LC1D40M7, Schneider LC1D40M7, 3 Pole Contactor 22kW, Industrial Contactor 22kW, 22kW Motor Contactor
Technical Specifications
- Number of Poles: 3
- Rated Operational Power: 22kW (AC-3, 400V)
- Auxiliary Contacts: 1NO + 1NC
- Coil Voltage: 220V AC 50/60Hz
- Rated Current: 40A (AC-3)
- Mounting: DIN rail or screw
- Electrical Endurance: 1.2 million cycles
- Mechanical Endurance: 10 million cycles
- Standards: IEC 60947-4-1
- Dimensions (H x L x W): 85mm x 100mm x 45mm
- Weight: 0.6 kg
Key Features
- Three-pole contactor for reliable switching
- Rated operational power: 22kW at 400V AC-3
- 1 Normally Open (NO) and 1 Normally Closed (NC) auxiliary contact
- Coil voltage: 220V AC 50/60Hz
- Compact and robust design for panel mounting
- High electrical and mechanical endurance
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with local electrical regulations and standards.
Applications
- Industrial motor control
- Lighting control circuits
- HVAC systems
- Pumping stations
- Automation panels
Standards & Compliance
- Complies with AS/NZS 60947 for low-voltage switchgear and controlgear
Environmental Benefits
- Enables efficient energy management in industrial systems
- Supports automation for reduced manual intervention and energy waste
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal 3P Contactor 22kW 1NO 1NC 220V AC (SCHLC1D40M7) is available for immediate purchase. Ideal for industrial motor control and automation panels.
