4.0mm2 Twin and Earth V90 Cable | 450/750V | 100m Roll
Electra Cables 4.0mm2 Twin and Earth V90 Cable, 450/750V rated, 100m roll, suitable for domestic, commercial, and industrial wiring applications with easy-peel PVC sheath and copper conductors.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: 4mm Twin and Earth Cable, 4mm2 T&E Cable, V90 Electrical Cable, PVC Sheathed Twin and Earth
Technical Specifications
- Conductor: Plain annealed copper (AS/NZS 1125)
- Insulation: PVC V90
- Sheath: 3V-90 Easytear White
- Voltage Rating: 450/750V
- Number of Cores: 2 cores plus earth
- Operating Temperature: 90°C
- Standard: AS/NZS 5000.2
- Insulation Colour: Red, White, Earth
- Sheath Colour: White
- Dimensions (H x L x W): 10mm x 100000mm x 10mm
- Weight: 3.5 kg
Key Features
- 4mm² Twin and Earth cable with 2 cores and earth
- 450/750V V-90 insulated with PVC sheath
- Easy-peel 3V-90 white sheath
- Plain annealed copper conductor compliant with AS/NZS 1125
- Normal operating temperature of 90°C
- Insulation colour coded Red/White/Earth
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 Wiring Rules.
Applications
- Domestic wiring
- Commercial wiring
- Industrial wiring
- Unenclosed installations
- Closed conduit installations
- Buried direct installations
- Underground duct installations where not subject to mechanical damage
Standards & Compliance
- AS/NZS 5000.2 – Electrical cables – Polyvinyl chloride (PVC) insulated cables of rated voltages up to and including 450/750 V
Environmental Benefits
- Durable PVC sheath reduces need for frequent replacements
- Copper conductor is recyclable
- Designed for long service life reducing waste
Warranty Information
Standard manufacturer warranty applies. Please refer to Electra Cables for detailed warranty terms.
Available Now
Available for immediate purchase. Ideal for domestic, commercial, and industrial electrical wiring applications.
