4G Low Band Yagi Antenna 698-960 MHz | 10m Cable | High Gain by Matchmaster
4G low band Yagi antenna with 698-960 MHz frequency range and 10 dBi gain—ideal for rural and remote signal enhancement. Built for wireless communication systems, with a 10m N Male to SMA Male cable for easy connectivity.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 4G Low Band Yagi Antenna 698 to 960 MHz with 10m N Male to SMA Male Cable
Brand: Matchmaster
SKU: 56MM-YG01
Alternatively Known As: 4G Low Band Yagi Antenna, 3G Yagi Antenna, Directional Cellular Antenna, Long Range Yagi Antenna
Technical Specifications
- Frequency Range: 698 to 960 MHz
- Peak Gain: 13-14 dBi
- VSWR: < 1.8:1 (703-790 MHz), < 1.5:1 (790-890 MHz)
- Azimuth Beamwidth: 45° (703-790 MHz), 37° (790-890 MHz)
- Elevation Beamwidth: 40° (703-790 MHz), 33° (790-890 MHz)
- Front to Back Ratio: > 16 dB (703-790 MHz), > 17 dB (790-890 MHz)
- Input Impedance: 50 Ω
- Polarisation: Vertical
- Max Input Power: 50 W
- Input Connector: N Female
- Cable: 300 mm RG-142 tail with 10m LMR 240 cable N Male to SMA Male
- Operating Temperature: -40 °C to 70 °C
- Mounting: Pole mount Ø 30-52 mm
- Construction Material: Aluminium with Black Powder Coat finish
- Dimensions (H x L x W): 70mm x 1290mm x 210mm
- Weight: 1.1 kg
Key Features
- 4G and 3G low band high-performance directional antenna
- 13-14 dBi peak gain over 698 to 960 MHz
- 300mm tail terminated with an N-type socket
- Supplied with 10m LMR 240 cable with N Male to SMA Male connectors
- Ruggedized construction for Australian conditions
- Factory tuned with no further tuning required
Professional Installation Requirements
- Professional installation by a qualified technician is recommended to ensure optimal antenna alignment and secure mounting.
Applications
- Ideal for Cel-Fi GO repeaters requiring long-distance cell tower connection
- Suitable for long-range rural sites up to 40km from base stations
- Cellular and 2-Way Radio communication setups
Standards & Compliance
- Complies with AS/NZS 60035 – Electrical Equipment in Explosive Atmospheres
Environmental Benefits
- Ruggedized design ensures durability and longevity, reducing waste
- Supports efficient signal reception reducing power consumption of connected devices
Warranty Information
Standard manufacturer warranty applies. Please refer to Matchmaster warranty policy for details.
Available Now
The Matchmaster 4G Low Band Yagi Antenna is available now for immediate purchase. Ideal for cellular and 2-way radio applications requiring long-range directional signal reception.
