4P Contactor 40A AC-1 | 2NO 2NC Contacts | 48VAC Coil | DIN Rail Mountable | @Pack of 1 | by Clipsal
The 4P Contactor 40A AC-1 is designed for reliable industrial motor control and lighting circuits, featuring 2 Normally Open and 2 Normally Closed contacts. With a 48VAC coil voltage and a compact DIN rail mountable design, it ensures efficient switching for both resistive and inductive loads, making it ideal for automation panels and HVAC systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 4P Contactor 40A AC-1 | 2NO 2NC Contacts | 48VAC Coil | DIN Rail Mountable | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHLC1D258E7
Alternatively Known As: 4 pole contactor, 40A contactor, 2NO 2NC contactor, Clipsal contactor 48VAC, SCHLC1D258E7, industrial contactor
Technical Specifications
- Number of Poles: 4
- Contact Configuration: 2NO + 2NC
- Rated Operational Current (AC-1): 40A
- Coil Voltage: 48VAC
- Mounting: DIN rail
- Frequency: 50/60Hz
- Utilization Category: AC-1/AC-3
- Mechanical Durability: 10 million operations
- Electrical Durability: 1 million operations (AC-1)
- Dimensions (H x L x W): 85mm x 95mm x 54mm
- Weight: 0.45 kg
Key Features
- 4 pole contactor with 40A AC-1 rating
- 2 Normally Open (NO) and 2 Normally Closed (NC) contacts
- 48VAC coil voltage
- Compact DIN rail mountable design
- Reliable switching for both resistive and inductive loads
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 wiring rules and local regulations.
Applications
- Industrial motor control
- Lighting circuits
- HVAC systems
- Switching of resistive and inductive loads
- Automation panels
Standards & Compliance
- Complies with AS/NZS 60947 for low-voltage switchgear and controlgear
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Enables efficient energy management in industrial and commercial installations
- Supports automation for reduced manual intervention and energy waste
Warranty Information
12 months warranty against manufacturing defects.
Available Now
The Clipsal 4P Contactor 40A AC-1 (2NO 2NC) 48VAC Coil (SCHLC1D258E7) is available for immediate purchase. Ideal for industrial motor control, lighting, and automation panels.
