5G/4G Log Periodic High Gain Antenna | Low PIM ≤-153dBc | 700MHz-6GHz | Weather-Resistant by Matchmaster
5G/4G log periodic high gain antenna with low PIM ≤-153dBc and 700MHz-6GHz frequency range—ideal for telecommunications. Built for robust communication, with weather-resistant construction for outdoor use.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 5G/4G Log Periodic High Gain Antenna - Low PIM ≤-153dBc
Brand: Matchmaster
SKU: 56MM-5G10
Alternatively Known As: 5G Log Periodic Antenna, 4G High Gain Antenna, Multi-band Cellular Antenna, Low PIM Directional Antenna
Technical Specifications
- Frequency Range: 698-960 MHz and 1700-3700 MHz
- Gain: 13 dBi (698-960 MHz), 14 dBi (1700-3700 MHz)
- Polarisation: Horizontal, Vertical, ±45°
- Horizontal Beam Width: 54°
- Vertical Beam Width: 47°
- VSWR: ≤1.7
- Isolation: >20 dB (698-960 MHz), >23 dB (1700-3700 MHz)
- PIM (2 x 43 dBm Carrier): ≤ -153 dBc
- Input Power: 50W
- Impedance: 50Ω
- Connector Type: 4.3-10 Female
- Material: Aluminium 6063T5, Black powder-coated
- Mounting Type: Pole
- Operational Temperature: <95°C
- Dimensions (H x L x W): 1365mm x 80mm x 205mm
- Weight: 1.9 kg
Key Features
- Multi-band directional antenna covering 694-960MHz and 1700-3700MHz
- High gain of 13/14 dBi across frequency bands
- Low PIM ≤ -153 dBc (Carrier 2 x 43 dBm) for minimal interference
- Polarization adjustable between vertical, horizontal, +45°, or -45°
- Black powder-coated welded aluminium construction with stainless steel mounting bracket
- Factory tuned with no further tuning required
- Lightweight design for easy mounting
- 4.3-10 female low loss connector
Professional Installation Requirements
- Professional installation by a qualified technician or installer is recommended to ensure optimal antenna performance and compliance with safety standards.
Applications
- Distributed Antenna Systems (DAS) for cellular coverage enhancement
- 5G, 4G, and 3G multi-band communication systems
- Large and small scale cellular and 2-way radio installations
- Pole mounting for outdoor cellular network infrastructure
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Durable powder-coated aluminium construction ensures long product life reducing waste
- Low PIM performance reduces signal interference, improving network efficiency and reducing energy consumption
Warranty Information
Standard manufacturer warranty applies. Please refer to Matchmaster warranty policy for details.
Available Now
The Matchmaster 5G/4G Log Periodic High Gain Antenna is available now for immediate purchase. Ideal for enhancing cellular network coverage in both large and small DAS solutions.
