Trade Discount 17%
5G Cellular Dipole Antenna | 600-6000 MHz | 5 dBi Gain | 3m Cable by Matchmaster
5G cellular dipole antenna with 600-6000 MHz range and 5 dBi gain—ideal for enhancing signal reception in telecommunication, commercial, and residential settings. Built for improved connectivity, with a 3-meter LL/LMR195 cable for easy installation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 5G Cellular Dipole Antenna with 3m LL/LMR195 Cable
Brand: Matchmaster
SKU: 56MM-5G01
Alternatively Known As: 5G Dipole Antenna, Cellular Dipole Antenna, 5G Omni Antenna, 5G Antenna with SMA Connector, Multi-band Cellular Antenna
Technical Specifications
- Frequency Bands: 690-960 MHz, 1710-2700 MHz, 3575-3700 MHz
- VSWR: 2.0:1 max
- Gain: 1.8-4.7 dBi
- Impedance: 50 Ohm nominal
- Radiation Pattern: Omnidirectional
- E Plane Beamwidth: 80 degrees
- Projected Area: 0.008370 square meters
- Power Handling: 5W
- Termination: 3m low loss LL/LMR195 cable with SMA male connector
- Wind Loading: 1.85 kg at 160 KPH
- Dimensions (H x L x W): 40mm x 186mm x 40mm
- Weight: 0.2 kg
Key Features
- 5G/4G/3G multi-band performance omnidirectional compact antenna
- Includes 3m low loss LL/LMR195 cable with SMA male connector
- Gain range from 1.8 to 4.7 dBi across 690-3700 MHz
- Factory tuned, no further tuning required
- Designed and manufactured in Australia
- Ground plane independent
- Can be mounted vertically or horizontally
Professional Installation Requirements
- Professional installation by a qualified technician is recommended to ensure optimal antenna placement and secure mounting.
Applications
- Fixed indoor and outdoor cellular communication installations
- 5G, 4G, and 3G network enhancement
- Wall bracket mounting for cellular and 2-way radio systems
Standards & Compliance
- Complies with AS/NZS 3112 – Plugs and Socket-Outlets (Type I Plug)
Environmental Benefits
- Compact design reduces material usage
- Low power loss cable enhances energy efficiency in signal transmission
Warranty Information
Standard manufacturer warranty applies. Please refer to Matchmaster warranty policy for details.
Available Now
The Matchmaster 5G Cellular Dipole Antenna with 3m LL/LMR195 Cable is available now for immediate purchase. Ideal for enhancing cellular signal reception in fixed indoor and outdoor applications.
