5G Low Profile Panel Antenna | 600MHz-5GHz | 2m Cable | Discreet Design by Matchmaster

BRAND: Matchmaster

SKU: 56MM-5G02

$139.10 List price: $168.30

+ −

30 Days Return Delivery Options

5G low profile panel antenna with 600MHz-5GHz range and 2m LL/LMR195 cable—ideal for telecommunications and mobile applications. Built for enhanced 5G performance, with discreet design for easy installation.

Description
Attachments

Product Name/Title: 5G Low Profile Panel Mounted Antenna with 2m LL/LMR195 Cable

Brand: Matchmaster

SKU: 56MM-5G02

Alternatively Known As: 5G Panel Antenna, Low Profile 5G Antenna, 5G Omni Antenna, 5G Cellular Antenna with SMA Cable

Technical Specifications

Frequency: 695-960, 1710-2700, 3500-3800 MHz
VSWR: < 2:1
Gain: 3dBi
Impedance: 50 Ohm nominal
Radiation Pattern: Omnidirectional
Polarization: Vertical
Projected Area: 0.008370 sqm
Power Handling: 5W
Humidity Range: 5-95%
Termination: 2m Low loss 195 Cable tail with SMA Plug
Dimensions (H x L x W): 77mm x 41mm x 41mm
Weight: 0.16 kg

Key Features

5G/4G/3G multi-band performance
Compact omnidirectional antenna
Includes 2m low loss LL/LMR195 cable with SMA male connector
3dBi gain across 695-3800MHz
Factory tuned, no further tuning required
Compact design only 77mm high
Requires 16mm mounting hole
Designed and manufactured in Australia

Professional Installation Requirements

Professional installation by a qualified technician is recommended to ensure optimal antenna placement and secure mounting.

Applications

Cellular and 2-Way Radio communication
Telemetry box mounting
5G, 4G, 3G multi-band wireless communication

Standards & Compliance

Complies with AS/NZS 60950 – Safety of IT and Communication Equipment

Environmental Benefits

Compact design reduces material usage
Low power loss cable improves energy efficiency in signal transmission

Warranty Information

Standard manufacturer warranty applies. Please refer to Matchmaster warranty policy for details.

Available Now

The Matchmaster 5G Low Profile Panel Mounted Antenna with 2m LL/LMR195 Cable is available now for immediate purchase. Ideal for cellular and telemetry applications requiring compact, multi-band antenna solutions.

Brochure (56mm-5g02_brochure.pdf, 314 Kb) [Download]

Full Product Catalogue (full-product-catalogue.pdf, 25,988 Kb) [Download]
