4G/5G Multiband Marine Antenna | 698-2700 MHz | Omnidirectional | Weatherproof by Matchmaster
Marine antenna with 698-2700 MHz frequency range and omnidirectional coverage—ideal for boats and yachts. Built for marine environments, with weatherproof design for reliable 4G/5G connectivity.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 8' 4G/5G Multiband Cellular Marine Antenna
Brand: Matchmaster
SKU: 56MM-5G09
Alternatively Known As: Marine 4G/5G Antenna, Multiband Cellular Marine Antenna, Omnidirectional Marine Antenna, 8-foot Marine Cellular Antenna
Technical Specifications
- Gain: 7.5dBi (690-960 MHz), 2.4dBi (1710-2700 MHz), 3.0dBi (3500-3700 MHz)
- VSWR: <2.2:1 Max both bands
- Impedance: 50 Ohms nominal
- Polarisation: Vertical
- Radiation: Omnidirectional
- Power Rating: 50 watts
- Cable: 5m Low loss LL195
- Termination: SMA Male Cable tail
- Base Materials: Fibreglass and Chromed Brass
- Antenna Length: 8’ (2430mm)
- Weight: 1.2kg
- Dimensions (H x L x W): 80mm x 2430mm x 80mm
- Weight: 1.2 kg
Key Features
- 4G/5G multiband performance covering 690-960 MHz, 1710-2700 MHz, and 3500-3700 MHz
- Omnidirectional marine-grade 8-foot white antenna
- 7.5dBi gain at 690-960 MHz, 2.4dBi gain at 1710-2700 MHz, 3.0dBi gain at 3500-3700 MHz
- Factory tuned with no further tuning required
- Fibreglass and thick-walled Radome construction
- Includes 5m low-loss LL195 input cable with SMA male connector
- Chromed Brass fittings for durability
- Simple and easy to use and install
Professional Installation Requirements
- Professional installation by a qualified technician is recommended to ensure optimal antenna placement and connection for marine environments.
Applications
- Marine communication systems
- 4G and 5G cellular network connectivity on boats and ships
- Omnidirectional signal reception for maritime environments
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Supports efficient communication reducing the need for multiple antennas
- Durable fibreglass construction extends product life and reduces waste
Warranty Information
Warranty details available upon request from Matchmaster; typically includes coverage against manufacturing defects.
Available Now
The Matchmaster 8' 4G/5G Multiband Cellular Marine Antenna is available now for immediate purchase. Ideal for marine communication and cellular network enhancement on boats and ships.
