A9 iC60H3 3P+Ns D Curve 20A 30mA A RCBO | High Inrush Protection | Compact DIN Rail Design | by Clipsal
The A9 iC60H3 3P+Ns D Curve 20A 30mA A RCBO combines circuit breaker and residual current device functionality, making it ideal for commercial and residential switchboards. With a 20A rated current and 30mA sensitivity, it provides robust protection against overloads, short circuits, and earth leakage, ensuring enhanced electrical safety in your installations.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: A9 iC60H3 3P+Ns D Curve 20A 30mA A RCBO | High Inrush Protection | Compact DIN Rail Design | by Clipsal
Brand: Clipsal
SKU: SCHA9DD1920
Alternatively Known As: Clipsal RCBO, 3 Pole RCBO, 20A D Curve RCBO, Residual Current Circuit Breaker with Overcurrent Protection, SCHA9DD1920
Technical Specifications
- Rated current: 20A
- Poles: 3P+Ns (3 pole + neutral switched)
- Tripping curve: D (10-14 In)
- Residual current sensitivity: 30mA (Type A)
- Rated voltage: 400V AC
- Breaking capacity: 6kA
- Mounting: DIN rail
- Standards: IEC/EN 61009-1, AS/NZS 61009.1
- Operating temperature: -25°C to +60°C
- Dimensions (H x L x W): 85mm x 78mm x 72mm
- Weight: 0.45 kg
Key Features
- Combined circuit breaker and residual current device (RCBO)
- 3 pole + neutral switched (3P+Ns) configuration
- D Curve for high inrush current protection
- 20A rated current
- 30mA residual current sensitivity (Type A)
- Provides protection against overloads, short circuits, and earth leakage
- Compact modular design for DIN rail mounting
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 and local regulations.
Applications
- Commercial and industrial electrical distribution boards
- Residential switchboards requiring combined circuit protection and residual current protection
- Protection of lighting, power, and sub-circuits
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 61009.1 – Residual current operated circuit-breakers with integral overcurrent protection
Environmental Benefits
- Enhances electrical safety, reducing risk of fire and electrical hazards
- Long operational life reduces replacement frequency and waste
Warranty Information
12 months manufacturer's warranty.
Available Now
Available for immediate purchase. Ideal for use in commercial, industrial, and residential switchboards requiring reliable circuit and residual current protection.
