AC 240V Solenoid Coil | IP65 Rated | Wide Operating Temperature | Din Plug Connection | by Aspen Pumps
The AC 240V Solenoid Coil is designed for reliable operation in refrigeration and HVAC systems, featuring an IP65 rating for dust and water resistance. With a wide operating temperature range from -40°C to 105°C and a maximum operating pressure of 31 bar, this solenoid coil ensures optimal performance in various applications. Ideal for industrial and commercial use, it is certified for safety and quality, making it a dependable choice for your system upgrades.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: AC 240V Solenoid Coil | IP65 Rated | Wide Operating Temperature | Din Plug Connection | by Aspen Pumps
Brand: Aspen Pumps
SKU: 707-240
Alternatively Known As: 240V Solenoid Valve Coil, AC Solenoid Coil, Refrigeration Solenoid Coil, HVAC Solenoid Coil
Technical Specifications
- Voltage: AC 240V
- Frequency: 50/60 Hz
- IP Rating: IP65
- Operating Temperature Range: -40°C to 105°C
- Maximum Operating Pressure: 31 bar
- Safe Working Pressure: 43 bar
- Connection Type: Din plug
- Certifications: UL, VDE, CQC
- Dimensions (H x L x W): 60mm x 50mm x 50mm
- Weight: 0.3 kg
Key Features
- Frequency: 50/60 Hz
- IP65 rated for dust and water resistance
- Wide operating temperature range from -40°C to 105°C
- High maximum operating pressure up to 31 bar
- Din plug connection for easy installation
- Certified UL, VDE, and CQC for safety and quality
- Safe working pressure (SWP) of 43 bar
Professional Installation Requirements
- Installation should be performed by a qualified technician or electrician to ensure compliance with electrical and safety standards.
Applications
- Refrigeration systems using HCFC, HFC, and A2L refrigerants
- Industrial and commercial solenoid valve operations
- HVAC systems requiring solenoid valve coils compatible with A1 and A2 refrigerants
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Compatible with low global warming potential refrigerants (A2L), supporting environmentally friendly HVAC solutions
- Durable design reduces replacement frequency and waste
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Aspen Pumps AC 240V Solenoid Coil is available for immediate purchase, ideal for refrigeration and HVAC system maintenance and upgrades.
