AJAX 12V-24V PSU for Hub 2 & Hub 2 Plus | Wide Input Voltage Range | Stable Output Voltage | by Dicker Data
AJAX 12V-24V PSU is designed for Hub 2 and Hub 2 Plus security systems, featuring a wide input voltage range from 8 to 32 V DC and a stable output voltage of 4.8 V DC ± 5%. Ideal for both residential and commercial security installations, this power supply ensures reliable performance with a maximum output current of 1.5 A, making it a perfect choice for your security needs.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: AJAX 12V-24V PSU for Hub 2 & Hub 2 Plus | Wide Input Voltage Range | Stable Output Voltage | by Dicker Data
Brand: Dicker Data
SKU: 27418.94.NC
Alternatively Known As: AJAX Power Supply Unit, AJAX PSU 12V-24V, Hub 2 Power Supply, Hub 2 Plus PSU
Technical Specifications
- Input Voltage: 8 - 32 V DC
- Output Voltage: 4.8 V DC ± 5%
- Turn-on Voltage: 8 V DC ± 2.5%
- Turn-off Voltage: 7–7.5 V DC depending on load
- Maximum Input Current: up to 1 A
- Maximum Output Current: 1.5 A
- Operating Temperature Range: -10 °C to +40 °C
- Humidity: Up to 75%
- Connection to Mains Socket: 6.5 × 2 mm
- Plug Size: 5.5 × 2.1 mm
- Dimensions: 98 × 70 × 17 mm
- Weight: 26 g
- Dimensions (H x L x W): 17mm x 98mm x 70mm
- Weight: 0.026 kg
Key Features
- Wide input voltage range from 8 to 32 V DC
- Stable output voltage of 4.8 V DC ± 5%
- Turn-on voltage at 8 V DC ± 2.5%
- Turn-off voltage between 7 and 7.5 V DC depending on load
- Maximum input current up to 1 A
- Maximum output current of 1.5 A
- Operating temperature range from -10 °C to +40 °C
- Humidity tolerance up to 75%
- Compact size with dimensions 98 × 70 × 17 mm
- Lightweight at 26 grams
Professional Installation Requirements
- Installation by a qualified electrician is recommended to ensure compliance with electrical safety standards and proper connection to the AJAX security system.
Applications
- Power supply for AJAX Hub 2 and Hub 2 Plus security systems
- Suitable for use in residential and commercial security installations
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption contributes to energy efficiency
- Compact design reduces material usage and waste
Warranty Information
2 years warranty provided by Ajax Systems Manufacturing from the date of purchase.
Available Now
The AJAX 12V-24V PSU for Hub 2 and Hub 2 Plus is available for immediate purchase, ideal for powering AJAX security hubs in residential and commercial settings.
