Auxiliary Contact Block 1 NC Early-Break + 1 NO Late-Make | 690V AC | IP20 by Clipsal
Auxiliary contact block with 1 NC early-break and 1 NO late-make configuration—ideal for industrial automation systems. Built for durability with 690V AC rating and IP20 protection, ensuring reliable performance in machinery control.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: TeSys Mini-Vario, Auxiliary contact block, 1 NC early-break+1 NO late-make
Brand: Clipsal
SKU: VZ7
Alternatively Known As: TeSys Auxiliary Contact Block, Mini-Vario Contact Block
Technical Specifications
- Rated operational voltage: 690 V AC 50/60 Hz
- Electrical durability: 30,000 cycles DC, 1,000,000 cycles AC-15
- Connections: screw clamp terminals for 2 cables 0.75-1.5 mm² flexible and 1-2.5 mm² solid
- IP Rating: IP20 conforming to IEC 60529
- Rated impulse withstand voltage: 8 kV
- Conventional free air thermal current: 12 A
- Conventional enclosed thermal current: 10 A
- Tightening torque: 0.7 N.m on screw clamp terminals
- Dimensions (H x L x W): 65mm x 48.5mm x 20mm
- Weight: 0.05 kg
Key Features
- 1 NC early-break and 1 NO late-make contact configuration.
- Rated operational voltage of 690 V AC.
- Mechanical durability of 100,000 cycles.
Professional Installation Requirements
- Professional installation by a qualified technician is recommended for optimal performance.
Applications
- Industrial: Automation systems, machinery control
Standards & Compliance
- Complies with IEC 60947-5 for safety and performance standards.
Environmental Benefits
- Packaging made with recycled cardboard.
- PVC free and halogen free product.
Warranty Information
18 months warranty against manufacturing defects.
Available Now
The Clipsal TeSys Mini-Vario Auxiliary Contact Block is available now for immediate purchase. Ideal for industrial automation and control systems.
