Braided 63A 25m Extension Lead 5Pin CEE 16mm² IP67 Grey Powersafe
This 25 metre braided 63A 5-pin CEE extension lead delivers IP67-rated three-phase power for industrial and construction sites. Rated to 400V AC with a 16mm² conductor size, it withstands operating temperatures from -25°C to +40°C. It complies with AS/NZS 3123 and AS/NZS 3820 for industrial plugs and socket-outlets. Technical specifications and installation requirements are detailed further down the page.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 25 Metre Braided 63A 5 Pin CEE Form Plug & Socket | IP67 Rated | Heavy-Duty Rubber | by Powersafe
Brand: Powersafe
SKU: E16mm/25/63/CEE
Alternatively Known As: 63A 5 pin extension lead, 63A 5 pin power cable, CEE Form 63A extension, industrial 5 pin power lead, IP67 63A extension cord
Technical Specifications
- Cable Length: 25 metres
- Current Rating: 63A
- Voltage: 400V AC (Three-phase)
- Pins: 5 (3P+N+E)
- Plug & Socket Type: CEE Form (IEC 60309)
- Cable Type: Braided heavy-duty rubber
- IP Rating: IP67 (dust tight and protected against immersion)
- Conductor Size: 16mm²
- Operating Temperature: -25°C to +40°C
- Dimensions (H x L x W): 120mm x 25000mm x 120mm
- Weight: 18 kg
Key Features
- 25 metre heavy-duty braided cable for durability
- 63A 5 pin CEE Form plug and socket for three-phase power
- IP67 rated for complete protection against dust and water immersion
- Suitable for harsh and outdoor environments
- High current capacity for demanding applications
Professional Installation Requirements
- Installation and connection should be performed by a licensed electrician to ensure compliance with safety standards and optimal performance.
Applications
- Industrial power distribution
- Construction sites
- Event and stage power supply
- Heavy-duty temporary power connections
- Mining and marine environments
Standards & Compliance
- Complies with AS/NZS 3123 – Industrial Plugs and Socket-Outlets
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Reusable heavy-duty cable reduces waste from frequent replacements
- IP67 rating ensures long service life, minimizing environmental impact
- Braided construction enhances durability, reducing resource consumption
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Powersafe 25 metre braided 63A 5 pin CEE Form plug and socket IP67 extension lead is available for immediate purchase. Ideal for industrial, construction, and event power distribution applications.
FAQ
Q: What is the current rating of this extension lead?
A: This Powersafe extension lead is rated to 63A with a 5-pin CEE Form plug and socket for three-phase power connections.
Q: What warranty does this extension lead come with?
A: It comes with a 12-month manufacturer's warranty against defects.
A 30 metre braided 63A 5-pin CEE extension lead provides the same IP67 protection for industrial power distribution.
A 15 metre braided 63A 5-pin CEE extension lead is also available in blue for three-phase site power.
A braided 32A 5-pin CEE extension lead is available for three-phase power distribution at a different current rating.
The 3-phase extension lead guide covers plug configurations and safety considerations for CEE Form connections like this one.
