Braided 63A 30m Extension Lead 5Pin CEE 16mm² IP67 Grey Powersafe
This 30 metre braided 63A 5-pin CEE extension lead delivers IP67-rated three-phase power for industrial and construction sites. Rated to 415V AC with a 16mm² conductor size, it's built for heavy-duty use across mining, marine and event power applications. It complies with AS/NZS 3123 and AS/NZS 3820 for industrial plugs and socket-outlets. Full specifications and installation requirements are listed further down the page.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 30 Metre Braided 63A 5 Pin CEE Form Plug & Socket | IP67 Rated | Heavy-Duty Construction | by Powersafe
Brand: Powersafe
SKU: E16mm/30/63/CEE
Alternatively Known As: 63A 5 pin extension lead, 63A 5 pin CEE cable, 63A 5 pin IP67 extension, industrial 5 pin power lead, 63A 5 pin braided cable
Technical Specifications
- Cable Length: 30 metres
- Current Rating: 63A
- Voltage: 415V AC (three-phase)
- Pins: 5 (3P+N+E)
- Plug & Socket Type: CEE Form (IEC 60309)
- Cable Type: Braided heavy-duty
- IP Rating: IP67 (dust tight and protected against immersion)
- Conductor Size: 16mm²
- Dimensions (H x L x W): 120mm x 30000mm x 120mm
- Weight: 18 kg
Key Features
- 30 metre heavy-duty braided cable for enhanced durability
- 63A 5 pin CEE Form plug and socket for three-phase power
- IP67 rated for complete protection against dust and water immersion
- Robust construction suitable for harsh environments
- High current capacity for demanding applications
Professional Installation Requirements
- Installation and connection should be performed by a licensed electrician to ensure compliance with safety standards.
Applications
- Industrial power distribution
- Construction sites
- Event and entertainment power supply
- Temporary site power
- Mining and heavy-duty environments
Standards & Compliance
- Complies with AS/NZS 3123 – Industrial Plugs and Socket-Outlets
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Reusable and durable construction reduces replacement frequency and waste
- IP67 rating prevents ingress of contaminants, extending product lifespan
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Powersafe 30 metre braided 63A 5 pin CEE Form plug and socket IP67 is available for immediate purchase. Ideal for industrial, construction, and event power distribution applications.
FAQ
Q: What is the current and voltage rating of this extension lead?
A: This Powersafe extension lead is rated to 63A and 415V AC three-phase, with a 5-pin CEE Form plug and socket.
Q: Is this extension lead suitable for outdoor use?
A: Yes, it's IP67 rated for complete protection against dust and water immersion, making it suitable for harsh outdoor and industrial environments.
A 25 metre braided 63A 5-pin CEE extension lead offers the same IP67 protection in a shorter length.
A 50 metre braided 63A 5-pin CEE extension lead is available in blue for larger site runs.
A braided 32A 5-pin CEE extension lead is available for three-phase power distribution at a different current rating.
The 3-phase extension lead guide covers CEE Form plug configurations and safety considerations relevant to this lead.
Order with confidence — SCHNAP offers a 30-day return policy on electrical products.
