Busbar Insulated 63A Three Phase MajorTech
MajorTech busbar features 63A rating, three phase and insulated construction. Ideal for switchboard connections.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Three-Phase Pin Busbar, Insulated Three-Phase Busbar, 63A DIN-Rail Busbar, VETi Three-Phase Busbar
Technical Specifications
- Model: VBUS3P
- Rated Current: 63 A
- Phase Configuration: Three-phase
- Connection Type: Pin type
- Insulation: Insulated construction
- Intended Use: Compatible VETi distribution boards and DIN-rail switchboards
- Typical Application Voltage: 230/400 V AC three-phase systems
- Dimensions (H x L x W): 27mm x 106mm x 21mm
- Weight: 0.1 kg
Key Features
- 63 A three-phase current rating
- Insulated construction for improved touch protection
- Pin-type connections for compatible modular protection devices
- Designed for MajorTech VETi distribution board accessories
- Reduces the need for multiple individual link wires
- Suitable for organised switchboard and distribution-board connections
Professional Installation Requirements
- Installation, modification and connection must be carried out by a licensed electrician in accordance with the manufacturer's instructions, AS/NZS 3000 and the applicable switchboard assembly requirements of AS/NZS 61439. Confirm compatibility with the installed circuit breakers before fitting.
Applications
- Three-phase residential distribution boards
- Commercial and light-industrial switchboards
- DIN-rail circuit-breaker interconnections
- VETi distribution-board installations
- Switchboard upgrades where compatible pin-type connections are required
Standards & Compliance
- Installation framework: AS/NZS 3000:2018 Wiring Rules
- Applicable switchboard assembly requirements: AS/NZS 61439.1 and AS/NZS 61439.2; compliance applies to the completed assembly and its verification, not automatically to the busbar as a standalone component
Environmental Benefits
- Copper conductors can be recovered and recycled at end of service life
- Insulated construction and reduced wiring complexity can help extend switchboard service life and reduce replacement waste
- A busbar connection system can reduce the quantity of individual connection wires and associated installation materials
Warranty Information
Major Tech publishes a 5-year warranty for distribution boards and enclosures. A separate warranty period for the VBUS3P busbar is not specifically stated; confirm classification and coverage with MajorTech or the authorised distributor. Australian Consumer Law rights continue to apply.
Available Now
Available through MajorTech and authorised Australian electrical distributors; confirm current stock and compatibility before ordering.
