C2C-EG13510A10000 | Safety light curtains
The SICK C2C-EG13510A10000 Safety Light Curtain Receiver deTec2 Core HG offers reliable industrial safety with a 14 mm resolution, 10 m scanning range, and robust IP65/IP67 protection for harsh environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: C2C-EG13510A10000 | Safety light curtains
Brand: SICK
SKU: 1220507
Alternatively Known As: Safety light curtain receiver, deTec2 Core safety sensor, industrial safety light barrier, SICK safety sensor receiver
Technical Specifications
- Product version: deTec2 Core HG
- Type: Type 2 (IEC 61496-1)
- Safety integrity level: SIL 1 (IEC 61508)
- Category: Category 2 (ISO 13849-1)
- Performance level: PL c (ISO 13849-1)
- PFHD: 31 x 10^-9
- Mission time: 20 years (ISO 13849-1)
- Safe state on fault: At least one OSSD is OFF
- System connection: Plug, M12, 5-pin with 150 mm cable length
- Cable diameter: 4.3 mm
- Power consumption: 3.6 W DC
- Supply voltage: 24 V DC (19.2 V to 28.8 V)
- Output: 2 PNP semiconductors, short-circuit protected, cross-circuit monitored
- Response time: 17 ms
- Protective field height: 1,350 mm
- Scanning range: 10 m
- Resolution: 14 mm
- Enclosure rating: IP65 and IP67
- Operating temperature: -30 °C to +55 °C
- Storage temperature: -30 °C to +70 °C
- Vibration resistance: 5 to 150 Hz, 3.5 mm / 1 g
- Shock resistance: 15 g / 6 ms
- Housing material: Aluminum extruded profile
- Front screen material: Chemically prestressed float glass
- Dimensions (H x L x W): 1350mm x 40mm x 50mm
- Weight: 3 kg
Key Features
- Receiver unit compatible with sender model 1220496
- Resolution of 14 mm and scanning range of 10 m
- Protective field height of 1,350 mm with no blind zones
- Optical synchronization and automatic calibration of protective field width
- Response time of 17 ms
- LED display elements for status indication
- Housing made of aluminum extruded profile with chemically prestressed float glass front screen
- Protection class III with IP65 and IP67 enclosure ratings
- Operating temperature range from -30 °C to +55 °C
- Shock resistance of 15 g / 6 ms and vibration resistance of 5 to 150 Hz
Professional Installation Requirements
- Installation must be performed by qualified personnel familiar with safety light curtain systems and compliant with relevant safety standards.
Applications
- Industrial safety in areas with coolants, lubricants, and cleaning agents
- Machine safeguarding and personnel protection
- Automation and manufacturing environments requiring safety light curtains
Standards & Compliance
- AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Durable construction reduces waste and replacement frequency
- Low power consumption of 3.6 W supports energy efficiency
- Long mission time of 20 years reduces environmental impact of frequent replacements
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK C2C-EG13510A10000 Safety Light Curtain Receiver is available for immediate purchase, ideal for industrial safety applications in harsh environments.
