Clamp Temperature Meter 600A AC/DC True RMS | Large Backlight LCD | Auto-Ranging & Overload Protection | by Wattmaster
The Clamp Temperature Meter 600A AC/DC True RMS is designed for precise electrical measurements, featuring a large backlight LCD for easy reading and True RMS for accurate AC measurements. Ideal for electrical troubleshooting and maintenance, this professional-grade meter includes a temperature probe and is perfect for qualified electricians and technicians.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Clamp Temperature Meter 600A AC/DC True RMS | Large Backlight LCD | Auto-Ranging & Overload Protection | by Wattmaster
Brand: Wattmaster
SKU: WATEL-9015
Alternatively Known As: Clamp Meter, True RMS Clamp Meter, Temperature Clamp Meter, AC/DC Clamp Meter
Technical Specifications
- Current Measurement: 600A AC/DC
- True RMS for accurate AC measurements
- Jaw Opening: 30mm max
- Display: Large backlight LCD
- Functions: Auto-ranging, data hold, overload protection
- Compliance: IEC 61010-1
- Power: Batteries included
- Dimensions (H x L x W): 180mm x 40mm x 70mm
- Weight: 0.5 kg
Key Features
- Professional grade clamp meter with True RMS measurement
- Supplied with test leads, temperature probe, batteries, carry case, and operating instructions
- Flexible and robust design with large backlight display
- Auto-ranging and auto power off for convenience
- Data hold function and overload protection
- Easy to use single rotary switch for function selection
- 30mm maximum jaw opening size
Professional Installation Requirements
- No professional installation required; suitable for use by qualified electricians and technicians.
Applications
- Electrical troubleshooting and preventative maintenance
- Measurement of AC/DC current up to 600A
- Temperature measurement with included temperature probe
- Suitable for professional electricians and technicians
Standards & Compliance
- Complies with AS/NZS 61010-1 – Safety requirements for electrical equipment for measurement, control, and laboratory use
Environmental Benefits
- Helps in efficient electrical system diagnostics reducing energy waste
- Durable design reduces need for frequent replacements
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Wattmaster Clamp / Temperature Meter 600A AC/DC True RMS is available now for immediate purchase. Ideal for electrical testing and maintenance applications.
