Coaxial Cable Low Loss RG11 75Ω Quad Shielded | Enhanced Signal Protection | Black LSHF Sheath | 300m Length | by Madison
Coaxial Cable Low Loss RG11 75Ω Quad Shielded is designed for optimal signal control and communication systems. With a robust black LSHF outer sheath and quad shielding, it ensures enhanced signal protection and compliance with ROHS standards. Ideal for professional installations, this cable operates efficiently in temperatures ranging from -25°C to +90°C, making it perfect for various applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Coaxial Cable Low Loss RG11 75Ω Quad Shielded | Enhanced Signal Protection | Black LSHF Sheath | by Madison
Brand: Madison
SKU: CC11QS300
Alternatively Known As: RG11 Quad Shield Coaxial Cable, Low Loss RG11 Cable, 75 Ohm Quad Shield Coax Cable
Technical Specifications
- Applicable Standards: UL758
- Number of Cores: 1
- Conductor: 23 AWG BC (Bare Copper), 1/0.6 mm stranding
- Conductor Area: 0.28 mm²
- Conductor Diameter: 0.6 mm
- Insulation Material: Solid PE
- Insulation Thickness: 1.5 mm
- Insulation Nominal OD: 3.7 mm
- Braiding Thickness: 0.84 mm
- Outer Sheath Material: LSHF (Low Smoke Halogen Free)
- Outer Sheath Colour: Black
- Outer Sheath Thickness: 1 mm
- Outer Sheath Nominal OD: 6.2 mm
- Max Conductor DC Resistance @ 20°C: 62.0 Ω/km
- Nominal Characteristic Impedance @ 1 MHz: 75±3 Ω
- Operating Temperature Range: -25°C to +90°C
- Minimum Bend Radius (Installation): 62 mm
- Approximate Mass: 5.5 kg per 100 m
- Supply Pack Type: Wooden Reel
- Dimensions (H x L x W): 22mm x 1000mm x 39mm
- Weight: 5.5 kg
Key Features
- Low loss RG11 coaxial cable
- Quad shielded for enhanced signal protection
- ROHS compliant
- Black LSHF outer sheath for safety
- Suitable for operating temperatures from -25°C to +90°C
- Minimum bend radius of 62mm for installation
Professional Installation Requirements
- Installation should be performed by qualified professionals to ensure proper handling and compliance with electrical standards.
Applications
- Signal control systems
- Communication systems
Standards & Compliance
- Complies with AS/NZS 60035 – Electrical Equipment in Explosive Atmospheres
Environmental Benefits
- ROHS compliant ensuring reduced hazardous substances
- Low smoke halogen-free (LSHF) outer sheath reduces toxic emissions in case of fire
Warranty Information
Standard manufacturer warranty applies. Please refer to Madison for specific warranty details.
Available Now
The Madison Coaxial Cable Low Loss RG11 75Ω Quad 300 is available for immediate purchase, ideal for signal control and communication system applications.
