Allen-Bradley 100C Coil Suppressor Diode Module 12 to 250VDC

Coil Suppressor Diode Module 12-250VDC | Surge Protection | Compact Design by NHP

BRAND: NHP

SKU: 100FSD250

$100.20 List price: $133.10

+ −

30 Days Return Delivery Options

Coil suppressor diode module with 12-250VDC range and surge protection—ideal for industrial contactor applications. Built for reducing electrical noise, with compact design for easy integration.

Description
Attachments

Product Name/Title: Allen-Bradley 100C Coil Suppressor Diode Module 12 to 250VDC

Brand: NHP

SKU: 100FSD250

Alternatively Known As: Coil Suppressor Diode, Surge Protection Module

Technical Specifications

Function: Diode
Voltage Type for Actuating: DC
Rated Control Supply Voltage: 12-250 V
Dimensions (H x L x W): 30mm x 100mm x 50mm
Weight: 0.2 kg

Key Features

Designed for DC voltage applications from 12V to 250V.
Provides surge protection for contactor coils.

Professional Installation Requirements

Professional installation by a qualified electrician is recommended for optimal safety.

Applications

Industrial: Used in contactor applications to suppress voltage spikes.

Standards & Compliance

Complies with relevant Australian standards for electrical safety.

Environmental Benefits

Helps in reducing electrical noise and prolonging the life of contactor coils.

Warranty Information

1 year warranty against manufacturing defects.

Available Now

The Allen-Bradley 100C Coil Suppressor Diode Module 12 to 250VDC is available now for immediate purchase. Ideal for industrial applications requiring surge protection.

Non-Returnable & Non-Cancellable

100FSD250-AU-Contactor-Coil-Suppressor-Datasheet.pdf (100FSD250-AU-Contactor-Coil-Suppressor-Datasheet.pdf, 268 Kb) [Download]
