DALI-2 LED Driver Kit | 1.2m Flex & Plug | Constant Current 550mA | Flicker-Free Dimming | by Ektor
The DALI-2 LED Driver Kit is designed for efficient LED lighting control, featuring a 1.2m flex and plug with a constant current of 550mA. Ideal for both commercial and residential applications, this driver ensures flicker-free dimming and operates within a temperature range of -20 to 50 °C, making it perfect for various indoor lighting setups.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: DALI-2 LED Driver Kit, DALI LED Driver with Flex and Plug, Constant Current LED Driver, Flicker-Free LED Driver
Technical Specifications
- Input Voltage: 230Vac (-6%/+10%)
- Input Frequency: 50 Hz
- Power Factor: 0.95
- Input Current: 0.14 A
- Driver Power: 22.8 W
- Driver Current: 550 mA
- Output Voltage Range: 6-38 V
- Surge Protection: 2kV L-N
- Standby Power: 0.5 W
- Operating Temperature: -20 to 50 °C
- Dimmable: Yes
- Wiring: Flex and Plug (2 pin) and 2 wire flying lead (DALI)
- Driver Mode: Constant Current
- Short Term Light Modulation (PstLM): 0.011
- Stroboscopic Visibility Measure (SVM): 0.005
- Dimensions (H x L x W): 40mm x 60mm x 120mm
- Weight: 0.3 kg
Key Features
- DALI DT6 LED Driver with full support for DT6 allowing flicker-free dimming
- Includes 1.2m 2 core flex and plug plus 2 core flying lead (DALI)
- Constant current driver mode
- Dimmable with compliant DALI-2 application controllers
- Surge protection of 2kV L-N
- Low standby power consumption of 0.5 W
- Operating temperature range from -20 to 50 °C
- Short Term Light Modulation (PstLM) ≤ 1.0 for minimal flicker
- Stroboscopic Visibility Measure (SVM) ≤ 0.4 to reduce visual discomfort
Professional Installation Requirements
- Installation by a qualified electrician is recommended to ensure compliance with electrical safety standards and proper integration with DALI lighting control systems.
Applications
- Commercial and residential LED lighting control
- DALI-2 compatible lighting systems requiring flicker-free dimming
- Indoor lighting installations with constant current LED drivers
Standards & Compliance
- AS/NZS 61347.1
- AS 61347.2.13
- AS CISPR 15
Environmental Benefits
- Energy-efficient LED driver reduces power consumption
- Low standby power minimizes energy waste
- Flicker-free dimming improves lighting quality and reduces health risks
Warranty Information
Standard manufacturer warranty applies. Please refer to Ektor for specific warranty terms.
Available Now
The Ektor Driver Kit - DALI-2 LED driver with 1.2m flex and plug set to 550mA is available for immediate purchase. Ideal for commercial and residential LED lighting control applications.
