Digital Clamp Meter | 0-600A AC/DC Range | 3½ Digit Backlit Display | CAT III 600V Rated | by Rapid Tech
The Digital Clamp Meter offers a comprehensive 0-600A AC/DC range and a 3½ digit backlit display, making it ideal for electrical maintenance and automotive servicing. With advanced functions like peak and min/max readings, this durable meter is designed for professionals who need reliable performance in various applications, ensuring safety and efficiency in monitoring electrical systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Digital Clamp Meter | 0-600A AC/DC Range | 3½ Digit Backlit Display | CAT III 600V Rated | by Rapid Tech
Brand: Rapid Tech
SKU: DCM340
Alternatively Known As: Digital Clamp Meter, AC/DC Clamp Meter, Megger Clamp Meter, Electrical Clamp Meter, Current Clamp Meter
Technical Specifications
- Current measuring range (AC): 0 – 600 A
- Current measuring range (DC): 0 – 600 A
- Voltage measuring range (AC): 0 – 600 V
- Voltage measuring range (DC): 0 – 600 V
- Electrical measurement category: CAT III 600 V
- Max resistance reading: 400Ω
- Display: 3½ digit, 4000-count backlit with digital bar graph
- Functions: Peak, min/max, data-hold, zero-offset REL mode
- Safety rating: IEC 61010-1 CAT III 600V
- Drop tested to 1.2 meters
- Dimensions (H x L x W): 180mm x 40mm x 80mm
- Weight: 0.5 kg
Key Features
- Comprehensive measurement range: 0 to 600A for AC/DC current and 0 to 600V for AC/DC voltage
- 3½ digit, 4000-count backlit display with high-resolution digital bar graph
- Advanced functions including peak, min/max, data-hold, and zero-offset REL mode
- Durable design rated to IEC 61010-1 CAT III 600V and drop-tested to 1.2 meters
- Versatile for various professional and niche applications
Professional Installation Requirements
- No professional installation required; however, users should have appropriate electrical knowledge to operate safely.
Applications
- Electrical maintenance and installation
- Automotive servicing and electric vehicle charging assessments
- Domestic power generation monitoring
- Battery monitoring and lift maintenance
- UPS commissioning and electroplating plants
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Enables efficient electrical system monitoring to reduce energy waste
- Supports maintenance of electrical equipment to extend lifespan and reduce electronic waste
Warranty Information
1-year manufacturer’s warranty against defects.
Available Now
The Rapid Tech Megger DCM340 Digital Clamp Meter is available now for immediate purchase. Ideal for professionals in electrical maintenance, automotive servicing, and domestic power monitoring.
