Electra 1mm 2 Core & Earth Flat Cable | 100 Metre Drum | PVC Insulation & Copper Conductors | by Electra Cables
Electra 1mm 2 Core & Earth Flat Cable is perfect for residential and commercial fixed wiring. With a durable PVC insulation and reliable 1mm² copper conductors, this cable ensures safety and efficiency in lighting circuits and power outlets. The 100 metre drum length allows for extended runs, making it ideal for various electrical installations.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Electra 1mm 2 Core & Earth Flat Cable | 100 Metre Drum | PVC Insulation & Copper Conductors | by Electra Cables
Brand: Electra Cables
SKU: SRF3010V-100WHE
Alternatively Known As: 1mm twin and earth cable, 1mm flat TPS cable, 2 core and earth electrical cable, 1mm² flat wire, Electra twin and earth 1mm
Technical Specifications
- Conductor size: 1mm²
- Number of cores: 2 + earth
- Conductor material: Plain annealed copper
- Insulation: PVC V-90
- Sheath: PVC 3V-90
- Voltage rating: 450/750V
- Maximum current rating: 10A
- Operating temperature: -15°C to +90°C
- Drum length: 100 metres
- Complies with AS/NZS 5000.2
- Dimensions (H x L x W): 4mm x 100000mm x 8mm
- Weight: 7.5 kg
Key Features
- 100 metre drum for extended runs
- 1mm² copper conductors for reliable conductivity
- 2 core plus earth configuration for safety
- Flat cable design for easy installation in confined spaces
- PVC insulation and sheath for durability and protection
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 wiring rules.
Applications
- Residential and commercial fixed wiring
- Lighting circuits
- Power outlets
- General electrical installations
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 5000.2 – Electric cables for working voltages up to and including 450/750V
Environmental Benefits
- PVC insulation is lead-free and compliant with RoHS standards
- Long drum length reduces packaging waste and installation offcuts
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Electra 1mm 2 Core & Earth Flat Cable 100 Metre Drum is available for immediate purchase. Ideal for residential and commercial fixed wiring applications.
