Encapsulated Distribution Board 24 Poles | 160A Main Switch | IP42 Rated | Grey by Clipsal
Encapsulated distribution board with 24 poles and a 160A main switch—ideal for residential, commercial, and industrial applications. Built for robust circuit protection, with IP42 rating and steel enclosure for enhanced durability.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Acti9, MB Encapsulated distribution board, 24 poles, 160A main switch, 18mm, IP42, grey
Brand: Clipsal
SKU: MB224C31
Alternatively Known As: Acti9 Distribution Board, Encapsulated DB, Circuit Protection Board
Technical Specifications
- Rated operational voltage: 415 V
- Rated operational current: 160 A
- Breaking capacity: 25 kA
- Rated insulation voltage: 500 V
- Rated impulse withstand voltage: 6 kV
- Enclosure material: Steel
- Network frequency: 50 Hz
- Poles description: 3P + N
- Dimensions (H x L x W): 750mm x 235mm x 580mm
- Weight: 31 kg
Key Features
- 24 poles with a 160A main switch for robust distribution.
- IP42 rated for protection against solid objects greater than 1mm and limited water ingress.
- Includes removable gland plates and a circuit schedule card.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, offices
- Commercial: Retail, hospitality, workspaces
- Industrial: Factories, warehouses, and large facilities
Standards & Compliance
- Pro-active compliance with EU RoHS directive.
Environmental Benefits
- Free of Substances of Very High Concern above the threshold.
- Toxic heavy metal free and mercury free.
Warranty Information
Standard warranty as per manufacturer guidelines.
Available Now
The Clipsal Acti9 Encapsulated Distribution Board is available now for immediate purchase. Ideal for residential, commercial, and industrial applications.
