Fibre Patch Lead 10 Metre Aqua LSZH | OM4 Multimode | Duplex LC Connectors | 2mm by Cabac
The MSS Fibre ST - LC OM4 10 Metre Aqua LSZH 2mm Duplex Fibre Patch Lead by Cabac is a high-performance fibre optic patch lead designed for data centres and telecommunications, featuring LSZH jacket and duplex LC connectors.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: MSS Fibre ST - LC OM4 10 Metre Aqua LSZH 2mm Duplex Fibre Patch Lead
Brand: Cabac
SKU: DSTLC10M-MM4AQ
Alternatively Known As: Fibre Optic Patch Lead, Duplex Fibre Patch Cable, OM4 Fibre Patch Lead, LSZH Fibre Cable, LC Duplex Patch Lead
Technical Specifications
- Connector Type: Duplex Clip on LC connectors
- Cable Jacket: LSZH (Low Smoke Zero Halogen)
- Cable Diameter: 2mm
- Fibre Type: OM4 Multimode
- Length: 10 metres
- Polarity Method: A-to-B
- Performance Tested to IEC 11801 and ANSI/TIA 568-3
- Standards Compliance: AS/CA S008, IEC 11801, 14763.36, ANSI/TIA 568-3, 61300-3
- Mating Cycles: Up to 500 (IEC 61300-2-2)
- RoHS and REACH Compliant
- Dimensions (H x L x W): 2mm x 10000mm x 2mm
- Weight: 0.05 kg
Key Features
- Performance tested to numerous IEC standards to ensure performance exceeds the requirement of test standards
- Range of connector types
- Duplex Clip on LC connectors
- LSZH Jacket in various colours
- Available in OM1, OM3, OM4 and SM
- Polarity method "A-to-B" used in all standard fibre patch leads with only LC connectors having duplex clips
- Up to 500 mating cycles (IEC 61300-2-2)
Professional Installation Requirements
- Professional installation by qualified technicians is recommended to ensure optimal performance and compliance with standards.
Applications
- Data centres
- Telecommunications rooms
- Fibre equipment patching
- CATV/Video
- PON
- WDM/DWDM
- FTTH
Standards & Compliance
- Complies with AS/CA S008 for telecommunications cabling
- Complies with IEC 11801 for generic cabling for customer premises
Environmental Benefits
- LSZH (Low Smoke Zero Halogen) jacket reduces toxic smoke and hazardous gases in case of fire, enhancing safety and environmental protection
- RoHS and REACH compliant, ensuring reduced hazardous substances and environmental impact
Warranty Information
Standard manufacturer warranty applies. Please refer to Cabac for specific warranty details.
Available Now
The MSS Fibre ST - LC OM4 10 Metre Aqua LSZH 2mm Duplex Fibre Patch Lead is available for immediate purchase, ideal for high-performance data centre and telecommunications applications.
