Filterfan 38m³/h 115V | IP54 Rated | Low Noise Operation | Compact Design | @Pack of 1 | by Clipsal
The Filterfan 38m³/h 115V is designed for effective ventilation in electrical enclosures and control panels. With an IP54 rating for dust and water splash protection, this fan operates quietly at ≤ 44 dB(A) and is easy to install. Ideal for industrial automation cabinets and switchboards, it enhances energy efficiency and extends the lifespan of sensitive components.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Filterfan 38m³/h 115V | IP54 Rated | Low Noise Operation | Compact Design | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHNSYCVF38M115PF
Alternatively Known As: Enclosure filter fan, Panel cooling fan, Electrical cabinet fan, SCHNSYCVF38M115PF
Technical Specifications
- Airflow: 38m³/h
- Voltage: 115V AC
- Frequency: 50/60Hz
- IP Rating: IP54
- Mounting cut-out: 125 x 125 mm
- Noise level: ≤ 44 dB(A)
- Filter material: Synthetic fiber
- Operating temperature: -10°C to +55°C
- Dimensions (H x L x W): 148mm x 62mm x 148mm
- Weight: 0.7 kg
Key Features
- Airflow capacity of 38m³/h for effective enclosure ventilation
- Operates at 115V AC
- IP54 rated for dust and water splash protection
- Compact and easy to install
- Low noise operation
- Long-life filter element
Professional Installation Requirements
- Installation by a qualified electrician is recommended to ensure proper sealing and electrical safety.
Applications
- Electrical enclosures
- Control panels
- Industrial automation cabinets
- Switchboards
- Data and telecom cabinets
Standards & Compliance
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Enhances energy efficiency by maintaining optimal enclosure temperature
- Extends lifespan of sensitive electrical components
- Reduces risk of overheating and associated waste
Warranty Information
12 months warranty against manufacturing defects.
Available Now
The Clipsal Filterfan 38m3/h 115V IP54 is available for immediate purchase. Ideal for ventilating electrical enclosures and control panels in industrial and commercial environments.
