Fire Rated Cable 1.50mm 2 Core | 450/750V | PVC Free & LSZH | 250m Roll by Firebox
Fire rated cable with 1.50mm 2 core construction and 450/750V voltage rating—ideal for fire alarm and emergency warning systems. Built for safety and compliance, featuring PVC free and low smoke zero halogen materials for reduced toxic emissions.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Fire Rated Cable 1.50mm 2 Core | 450/750V | PVC Free & LSZH | 250m Roll by Firebox
Brand: Firebox
SKU: FR-1.50-2CW-250
Alternatively Known As: Fire Rated Speaker Cable, 2 Core Fire Alarm Cable, LSZH Fire Rated Cable, FireSense 2HR Cable
Technical Specifications
- Voltage Rating: 450/750V
- Temperature Rating: 110°C continuous operation
- Fire Rating: 2HR Fire Rated – WS52W
- Cable Construction: AS/NZS 5000.2 compliant
- Fire & Mechanical Protection: AS/NZS 3013, AS/NZS 4507 (RHE-3)
- ACMA Compliance: AS/CA S008
- Markings: AS 1670:2018
- Twists: 8-10 twists per meter
- Length: 250m roll
- Dimensions (H x L x W): 10mm x 250000mm x 10mm
- Weight: 5 kg
Key Features
- 2HR Fire Rated – WS52W
- White stripe for speaker circuit identification
- PVC Free - Low Smoke Zero Halogen (LSZH) certified by Bureau Veritas & GECA
- ActivFire certified
- RCM / Global Mark certified
- Green Building Code of Australia / Green Star compliant
- 110°C continuous operation
- 450/750V voltage rating
- Fire & Mechanical Protection compliant with AS/NZS 3013, AS/NZS 4507 (RHE-3)
- Cable Construction compliant with AS/NZS 5000.2
- ACMA Compliance with AS/CA S008
- AS 1670:2018 Markings
- 8-10 twists per meter for flexibility
- Smallest diameter on the market
- Flexible, easy to strip, install & terminate
Professional Installation Requirements
- Installation should be performed by a qualified electrician familiar with fire rated cable standards and local regulations to ensure compliance and safety.
Applications
- Low Voltage (LV) applications
- Emergency Warning and Intercommunication Systems (EWIS) speaker circuits (100V line)
- Fire alarm systems
- Fire and mechanical protection wiring
Standards & Compliance
- AS/NZS 3013 – Electrical installations – Fire resistant cables
- AS/NZS 5000.2 – Electrical cables – Polymeric insulated
- AS/NZS 4507 – Fire resistant cables – Mechanical protection
- AS/CA S008 – Requirements for customer cabling products
- AS 1670:2018 – Fire detection, warning, control and intercom systems
Environmental Benefits
- PVC Free and Low Smoke Zero Halogen (LSZH) materials reduce toxic emissions during fire
- Certified by Bureau Veritas and Good Environmental Choices Australia (GECA)
- Complies with Green Building Code of Australia and Green Star requirements
Warranty Information
Warranty details available upon request from Firebox, typically covering manufacturing defects.
Available Now
The FireSense Fire Rated Cable 1.50mm 2 Core with White Stripe 250m Roll is available now for immediate purchase. Ideal for fire alarm and EWIS speaker circuit applications requiring certified fire rated cable.
