Flat Head Screw ISO 7045 | H Cross Recess | Zinc Plated Blue Passivated | M3x30 | @Pack of 50 | by Wurth
Flat Head Screw ISO 7045 with H cross recess and zinc plated blue passivated surface — ideal for general mechanical fastening. Built for electronics assembly and automotive repairs, with corrosion resistance and moderate strength (Property class 4.8).
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Flat Head Screw ISO 7045 | H Cross Recess | Zinc Plated Blue Passivated | M3x30 | @Pack of 50 | by Wurth
Brand: Wurth
SKU: 5103003030
Alternatively Known As: Flat head cross recess screw, ISO 7045 screw, Pan head screw M3x30, Zinc plated flat head screw
Technical Specifications
- Thread type x nominal diameter: M3
- Length: 30 mm
- Head diameter: 5.6 mm
- Head height: 2.4 mm
- Standards: ISO 7045
- Material: Steel
- Property class: 4.8
- Surface: Zinc plated blue passivated
- RoHS-compliant: Yes
- Head type: Pan head
- Drive type: Crosshead
- Internal drive: H1
- Thread type: Metric thread
- Pitch: 0.5 mm
- Thread form: Standard metric thread
- Product class: A
- Dimensions (H x L x W): 2.4mm x 30mm x 5.6mm
- Weight: 0.01 kg
Key Features
- Complies with ISO 7045 standard replacing DIN 7985
- Flat head design with H cross recess for secure drive
- Steel material with zinc plated blue passivated surface for corrosion resistance
- Metric thread M3 with 0.5 mm pitch
- Property class 4.8 ensuring moderate strength
- RoHS-compliant
Professional Installation Requirements
- Installation by a qualified technician or tradesperson recommended to ensure proper fastening and safety.
Applications
- General mechanical fastening
- Electronics assembly
- Automotive repairs
- Industrial machinery
- Furniture assembly
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- RoHS-compliant ensuring reduced hazardous substances
- Zinc plating provides corrosion resistance extending product life and reducing waste
Warranty Information
Standard manufacturer warranty against defects applies.
Available Now
Wurth Flat Head Screw with H Cross Recess ISO 7045 Steel Zinc Plated M3x30 is available for immediate purchase, ideal for mechanical and industrial fastening applications.
