GRSE18-P2427 | Photoelectric sensors
The SICK GRSE18-P2427 is a through-beam photoelectric sensor featuring a cylindrical M18 housing, infrared LED light source, and a sensing range up to 15 meters, ideal for industrial automation and object detection applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: GRSE18-P2427 | Photoelectric sensors
Brand: SICK
SKU: 1064922
Alternatively Known As: Through-beam photoelectric sensor, Infrared photoelectric sensor, M18 photoelectric sensor, Industrial object sensor
Technical Specifications
- Functional principle: Through-beam photoelectric sensor
- Sensing range max.: 0 m to 15 m
- Type of light: Infrared light (850 nm wavelength)
- Light source: LED
- Light spot size at 10 m: Ø 420 mm
- Adjustment: Potentiometer
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 30 mA
- Switching output: PNP, complementary
- Switching mode: Light/dark switching
- Response time: < 500 µs
- Switching frequency: 1,000 Hz
- Connection type: Male connector M12, 4-pin
- Circuit protection: Types A, B, D
- Protection class: III
- Housing material: Plastic, ABS
- Optics material: Plastic, PMMA
- Enclosure rating: IP67
- Operating temperature: -25°C to +55°C
- Storage temperature: -40°C to +70°C
- EMC compliance: EN 60947-5-2
- Dimensions (H x L x W): 18mm x 74mm x 18mm
- Weight: 0.1 kg
Key Features
- Through-beam photoelectric sensor with infrared light source
- Sensing range up to 15 meters
- Cylindrical housing design with M18 x 1 thread diameter
- LED indicators for power and object detection status
- High switching frequency of 1,000 Hz
- IP67 rated enclosure for dust and water protection
- Operating temperature range from -25°C to +55°C
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper connection and compliance with safety standards.
Applications
- Industrial automation for object detection
- Material handling and conveyor systems
- Safety and security systems
- Packaging and manufacturing processes
Standards & Compliance
- AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Low power consumption with efficient LED light source
- Durable IP67 rated housing reduces waste from replacements
- Complies with China RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK GRSE18-P2427 Through-beam Photoelectric Sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
